UA-66 Urine Analyzer Operator’s Manual
-1-
1 Introduction
1.1 Specifications
Power Required AC 220V 50/60Hz
(AC 110V 50/60Hz)
Line Leakage Current ≤ 0.5 mA
Dimensions Width: 360 mm (14.2 in.)
Depth: 300 mm (11.8 in.)
Height: 100 mm (3.94 in.)
Weight 3.8 Kg
Ambient Operating
Temperature range
10 to 30 ℃ ℃
Ambient Operating
Humidity range
≤80%
Atmospheric pressure 76kPa-106kPa
Transport and storage conditions Temperature: 0℃-40℃
Relative humidity: ≤80%
Testing Type Reflectance Photometer
Light Source LED
Wavelength R (red), G (green), B (blue)
Work Flow 60 seconds( single step mode )
60 seconds( slow batch mode )
30 seconds( fast batch mode )
Printer
External printer 、micro thermo printer, width 57 mm,
diameter<50mm.
Display Liquid Crystal Display with back light, 240*128 dots
Interface RS-232C, DB9 female
Testing items Leukocytes, Urobilinogen, Bilirubin, Nitrite, pH,
Specific Gravity, Blood, Glucose, Protein, Ketone,
Ascorbic Acid
Usable Strip U-10 Para. & 11 Para
Table 1.1
