Place the armrest onto the top of the upper
shaft, lining up the central hole in the
armrest with a hole in the aluminium shaft.
Position the armrest to suit your arm length.
(Holding the Detector, pg. 15)
Insert the screw up through the stand, upper
shaft and armrest. Tighten the screw, being
careful not to overtighten and damage the
thread.
With the velcro side facing upwards, thread
the armrest strap through both slots in the
armrest. Ensure the end of the strap will
be fastened outwards from your arm.
The X-Terra is designed to be used in both the
left and right hand. This diagram shows the
velcro strap threaded outwards for the left arm.
10
