Minelab X-Terra 50 User Manual

Wind the coil cable around the lower
and middle shaft enough times to take
up the slack.
Use the velcro tabs to keep the coil cable
in place against the shaft. It is recommended
that one tab is used on the lower shaft close
to the coil and the other tab on the middle
shaft before the cable reaches across to
the control box.
Align the coil plug and connect into
the socket in the back of the control box,
lightly tightening the retaining ring to
hold it in place.
12

Minelab X-Terra 50 Specifications

General

Brand	Minelab
Model	X-Terra 50
Category	Metal Detector
Language	English
