8
Plug the two rubber washers into the holes
on either side of the lower shaft yoke.
Slide the yoke into the yoke bracket on top
of the coil. Ensure that the spring loaded
pin in the lower shaft is underneath.
Insert the plastic bolt through the yoke
and the yoke bracket.
Fasten with the plastic wing nut provided,
being careful not to damage the thread
of the bolt by over-tightening. This may
need to be loosened to adjust the coil to
a comfortable detecting angle.
The coil cable is directly wired into the
coil and is not removable. Any attempt to
disconnect this cable will void your warranty.
