Assembly Part # Description Notes Quantity
B 2770219 t COVER KIT, RIPTIDE POWERDRIVE *I-PILOT COVER & DECALS ONLY* 1
Y 2774126 t MOTOR KIT, iP 1.6 RT POWERDRIVE *i-PILOT RECEIVER* 1
Item Part # Description Notes Quantity
2 2031522 COLLAR DRIVE (W/INSERT) 1
4 2323104 HEX NUT ¼ -20 SS 1
6 2011366 SCREW-COLLAR/NEW KNOB(SS) *SALTWATER* 1
8 2292506 CONTROL BOX A/P RT-WHITE *SALTWATER* 1
10 2224707 PLUG, SCREW-DOWN, WHT 1
12 2372103 SCREW-#6 X .375 PLASTITE SS 2
14 2305402 SHRINK TUBE-.374 OD X 2.25" *SALTWATER* 2
16 2263406 SCREW-#10-24 X 2" S/S PPH 1
18 2333101 NUT-HEX #10-24 UNC-2B NYL SS *SALTWATER* 1
20 2372100 SCREW-#8-18 X 5/8 THD* (SS) 5
22 2290218 COVER, CTRL BOX, RT PD PRINTED 1
24 2290213 t COVER, CTRL BOX RT PD PRINTED *iPILOT* 1
26
2315608 DECAL, COVER, RT PD 55 *55LB* 1
2315607 DECAL, COVER, RT PD 50 *70LB* 1
2315731 DECAL-GENERIC, PUSH BTN TOP SW 1
2395551 t DECAL, PUSH BTN RT PD, TRV/iP 55 *iPILOT* 1
2315604 t DECAL, PUSH BTN TOP, RT V3 70iP *iPILOT* 1
28 2390800 t LANYARD, REMOTE W/ CARABINER 1
30 2390801
l LANYARD, REMOTE *COPILOT* 1
32 2994075 t REMOTE ASSY, IPILOT 1.6 1
34 2256300 TIE WRAP - 5.5" BLACK *70LB* 1
36 2395546 t DECAL. DOMED iPILOT SW 1
38 2994123
l RECIEVER ASM CO-PILOT SW 1
40 2373418
l SCREW-#8 X 5/8 PPHSMS S/S *COPILOT ONLY* *SALTWATER* 2
42 2994020
l TRASMTR, ASY, PD/AP COPLT *COPILOT ONLY* *SALTWATER* 1
p
2397100 t MANUAL, iPILOT 1.6 *i-PILOT* 1
p
2397106 t GUIDE-QUICK REFERENCE iP 1.6 *iPILOT* 1
p
2015800 HANG TAG "CAUTION... TILT HINGE" 1
p
2317123 MANUAL, INSTALL GUIDE, RTPD BT 1
p
2297165 MANUAL, DISCLAIMER, DOWNLOAD INFO 1
p
2317121 MANUAL, RT POWERDRIVE BT 1
Control Head Parts List
p Not shown on Parts Diagram.
✖
This part is included in an assembly and cannot be ordered individually.
t
Only available with models factory installed with i-Pilot or i-Pilot Link.
l Only available with models factory installed with CoPilot.
