MINN KOTA RT55SP - Parts Diagram & Parts List; Riptide PowerDrive Control Head

RIPTIDE POWERDRIVE - 55/70 LBS THRUST - 12/24 VOLT - 48”/54” SHAFT
The parts diagram and parts list provides Minn Kota
®
WEEE compliance disassembly instructions. For more information about where
you should dispose of your waste equipment for recycling and recovery and/or your European Union member state requirements, please
contact your dealer or distributor from which your product was purchased. Tools required, but not limited to: flat head screwdriver,
Phillips screwdriver, socket set, pliers, wire cutters.
minnkotamotors.com | 37
©2021 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Control Head Parts Diagram
