PARTS DIAGRAM & PARTS LIST
Foot Pedal Parts List
Assembly Part # Description Notes Quantity
C 2994728 FOOT PEDAL ASSEMBLY, PD 1
Z 2994859 BAG ASY-TERROVA/V2,RUB.BUMPERS 1
Item Part # Description Notes Quantity
260 2300275 COVER-SPEED SELECTOR,PD FP,BLK 1
262 2302730 SPRING-LONG-UPPER PEDAL 3
264 2302732 SPRING-LOWER PEDAL S/S 1
266 2303725 BUTTON-MOMENTARY, PD FP, BLK 1
268 2303730 BUTTON-MOM/CON, PD FP, BLK 1
270 2304406 PEDAL, STRG ROCKER, PD FP, BLK 1
272 2304508 BASE, PEDAL PD 1
274 2305136 BUMPER,STRG RCKR,PD FP,RUBBER 2
276 2307905 WHEEL-SPEED, PD FP, BLK 1
278 2308609 SWITCH LEVER, SINGLE 1
280 2302105 SCREW #6-19 X 3/8 HIGH-LOW SS 14
282 2335130 BUMBER ACTUATOR 2
284 2994053 PCB/CTRL CORD, PD FT PEDAL 1
286 2301750 WASHER, WAVE, PD V3 FP 1
288 2316600 DECAL-ON/OFF SWITCH/PD V2 PED 1
290 2325110 PAD, FOOT PEDAL PD 5
