Assembly Part # Description Notes Quantity
A 2994864 BAG ASSEMBLY - (BOLT, NUT, WASHERS) 1
D 2884058 CONTROL BOARD-24V V2 W AP W/SHRNK *AUTOPILOT* 1
E 2884055 CONTROL BRD-12V V2 W/O AP W/SHRNK 1
F 2884057 CONTROL BOARD-12V V2 W/AP W/SHRNK *AUTOPILOT* 1
G 2884056 CONTROL BRD-24V V2 W/O AP W/SHRNK 1
Item Part # Description Notes Quantity
302 2301937 EXTRUSION BASE PD V2 *SALTWATER* 1
304 2303932 MOTOR REST-RIGHT, 3 5/8" 1
306 2303937 MOTOR REST-LEFT, 3 5/8" 1
308 2332104 SCREW-1/4-20 X 5/8 S/S *SALTWATER* 9
310 2335110 PAD-PIVOT SUPPORT(SS) *SALTWATER* 4
312 2305103 PIVOT PAD,559 FB DUROMETER 90A 2
314 2330510 PIN-LATCH (PD BASE)SS *SALTWATER* 1
316 2330520 PIN-PIVOT (PD BASE)SS *SALTWATER* 1
318 2333100 NUT-SPEED (SS) *SALTWATER* 4
320 2303612 ROD-RELEASE (RT/AP) S/S 1
322 2322700 SPRING-TORSION 1
324 2333705 LEVER-RELEASE S/S *SALTWATER* 1
326 2300101 RELEASE-KNOB 1
328 2301700 SPACER-RELEASE LEVER-BRASS 1
330
2304067 CONTROL BOARD-24V V2 W/AP *AUTOPILOT* 1
2304064 CONTROL BRD-12V V2 W/O AP 1
2304066 CONTROL BOARD-12V V2 W/AP *AUTOPILOT* 1
2304065 CONTROL BRD-24V V2 W/O AP 1
332 2303434 SCREW-#8-32 X 5/8 MACH PHCR SS 3
334 2090651 LEADWIRE,10 GA, PD/GENESIS 1
336 2321310 STRAIN RELIEF 1
338 2323405 SCREW-1/4-20 X 1/2" MCH SS 1
340 2306571 HOUSING-CENTER RT-WHITE *SALTWATER* 1
342
2074081 BATTERY METER, 24V *SALTWATER* *70LB* 1
2074080 BATTERY METER, 12V *SALTWATER* *55LB* 1
344 2383428 SCREW-#4-24 X 5/8 HI-LO SS 1
346 2320710 TERMINAL-AMP (T-TAB) 1
348 2325401 SHRINK TUBE-3/4 ID X 2" W/ADHS 1
350 2305642 DECAL,BATTERY METER PD V2 SW *SALTWATER* 1
p
Not shown on Parts Diagram.
✖
This part is included in an assembly and cannot be ordered individually.
t
Only available with models factory installed with i-Pilot or i-Pilot Link.
l Only available with models factory installed with CoPilot.
50 | minnkotamotors.com
©2021 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Mount Parts List
