Mirtone QuickStart Front Panel Programming Getting Started Guide 20
Card configuration - SLIC
After setting up the basic system options, it’s time to begin entering the Signature device
information. If you’re continuing on from the previous topic, you should be at the
Configure menu. If not, log in as a level 4 user and navigate through the menus to return
to the Configuration menu.
CONFIGURE CARDS SLIC CONFIGURE CARD
1) AutoLearn 1) Add 1) Config Card 1) NAC1
2) System 2) Edit 2) Config Detect 2) NAC2
3) Cards 3) Delete 3) Config Module 3) Wiring Class
4) Zone 4) Autoloop 4) Exit
5) Outputs 5) Accept Map
6) Exit 6) Exit
To configure an SLIC card
1. Choose Cards > Edit.
2. Enter the address of the SLIC.
3. From the SLIC menu choose Config Card.
4. Choose NAC1 and set the signal circuit to be either audible or visual.
For our example NAC1 is visual, which is the default.
5. Choose NAC2 and set the signal circuit for either audible or visual.
For our example NAC2 is audible.
6. Choose Wiring class and choose either Class A or Class B.
In our example project, the wiring is Class B.
7. Choose Exit and Save Edits.
This returns you to the SLIC menu.
Note: By default, circuits configured as visual are non-silenceable.
Next, we’ll enter information for the Signature detectors.
