Mirtone QuickStart Front Panel Programming Getting Started Guide 5
Example project details
Here are the details of the project we use as our front panel programming example.
Application
• Four story building
• Four multisensor smoke detectors located in the elevator lobbies
• Three photoelectric smoke detectors and four fixed heat detectors located in the
elevator machine room
• Four photoelectric smoke detectors in electrical rooms on each floor
• Five duct smoke detectors located on the air handling units
• Signal circuit per floor
• Monitor kitchen hood releasing system and transmit CID
• Monitor sprinkler system waterflow and tampers and transmit CID
• Activate shut off gas valve upon alarm from kitchen hood system
• Activate relays for primary elevator recall and alternate elevator recall
• Activate relay shunt trip breaker for elevator power shut off
• Activate relay for alarm notification in the elevator machine room
• Activate fan shut down relays on building waterflow activation
• Contact ID configuration for dialer
Hardware
Qty Model Description
1 MIR-QS4-5-G-1 QuickStart control panel with 5 option slots
1 SLIC Signature Loop Interface Card
1 DLD Dual Line Dialer
1 Batteries Sized for 60 hours standby
1 MIR-QS4-CPU-1 Remote annunciator
1 QSA-1-S Backbox for annunciator
8 GSA-M278 Intelligent manual station, double action
