Installation and Configuration Guide
12
TABLE 1 lists the common gateway commands and settings with descriptions.
For a description of gateway commands, refer to “Appendix G: Menu Structure” on page 41.
To configure the gateway, you require
• A PC with a communications program such as “HyperTerminal”
• An RS-232 straight-through cable
Connect a Maintenance PC to the 3300 CITELlink Gateway
1. Connect an RS-232 straight-through cable from the gateway’s serial port to the serial port
on a PC.
2. From the PC, launch a communication program and configure the PC’s serial port to use
the following settings:
Table 1: Commands and Settings
Command Description
[support]ifconfig
Displays current gateway settings
[sys]setconfig
Allows user to edit gateway settings
[support]ver
Displays firmware version
[boot]nupdatef
Loads firmware upgrade
[boot]reboot
Reboots the gateway
[support]su
Changes to privileged access
Ctrl-D
Exits from privileged access
IP Address settings: Note: To use DHCP, set all IP addresses to “0.0.0.0”.
• myIpAddress IP address of the 3300 CITELlink Gateway
• myIpNetMask The net mask
• defaultRouter IP address of the default router
• configAddress IP address of the TFTP server
• pbxIpAddress IP address of the 3300 ICP
• sysLogAddress Leave set to “0.0.0.0”
dhcpEnabled Enables or disables DHCP IP addressing. Set to “TRUE” (to
enable) or “FALSE” (to disable). (Default is TRUE.)
autoUpdate Enable or disable automatic upgrades. Set to “TRUE” (to enable)
or “FALSE” (to disable). (Default is TRUE.)
Table 2: PC-to-3300 CITELlink Gateway Serial Settings
Baud Rate
115200
Stop Bits
1
Data bits
8
Flow Control
None
Parity
None
