Installation and Configuration Guide
2
Once connected and programmed on the system, Meridian 1 sets—including displays, softkeys,
and supported hardkeys—operate like Mitel phones.
By default, the gateway is configured to use DHCP IP addressing and to load software updates
on startup. If required, these defaults can be changed using a command-line tool included with
the gateway.
The 3300 ICP supports any combination of Mitel and CITELlink-supported phones up to the
maximum capacity of the 3300 ICP controller. A 700 -user controller, for example, supports a
maximum of 29 gateways (700 limit ÷ 24 phones per gateway).
The gateway is supported on 3300 ICP systems with Release 5.2 software or higher.
Supported Meridian 1 Sets
The gateway supports the following Meridian 1 models:
Supporting Documentation
The following documentation is available on Mitel Online at http://www.ebiz.mitel.com:
• 3300 CITELlink Start Here Guide–identifies the documentation that you need, provides
important safety instructions, and details regulatory approvals.
• 3300 ICP System Administration Tool Online help–provides instructions on how to configure
phones on the 3300 ICP system.
• 3300 CITELlink Phone User Guides–identifies the functions of the Meridian 1 phone keys
and provides feature operation instructions.
• 3300 Integrated Communications Platform Technician’s Handbook–provides instructions
on how to configure the 3300 ICP DHCP server and launch the System Administration tool.
• LAN Design Guidelines for the Implementation of 3300 Platforms–provides further details
on setting up the LAN and Layer 2 switches.
Important Safety Instructions
WARNING: Before attempting installation, read the Safety Instructions provided in the
3300 CITELlink Gateway Start Here Guide. This guide is shipped with the gateway.
WARNING: Failure to follow all instructions may result in improper equipment operation
and/or risk of electrical shock.
• A2008 • M2006 • M2008 • M2616
• M3110 • M3310 • M3820 • M3901
• M3902 • M3903 • M3904
Note: The following Meridian 1 devices are NOT supported: Analog terminal adapter (ATA),
M2616CT, Key expansion module, external alerter interface, Meridian communications adapter
(MCA), Meridian programmable data adapter (MPDA), attendant consoles.
Note: You require a Mitel Online username and password to access the site, and Adobe Acrobat
Reader to view some online guides.
