Before You Begin
3
Before You Begin
This chapter lists the tools and information required for installation and describes how to
• Prepare the network, including testing existing sets and cabling, checking DHCP configu-
ration (if required), and checking Layer 2 switch configuration.
• Program the 3300 ICP, including the DHCP server, licenses, feature access codes (FAC),
Meridian 1 sets, and phone keys.
• Prepare users by distributing user guides, FAC reference cards, and phone key labels.
When planning the installation, note that the gateway:
• Supports a maximum of 24 sets
• Supports ONLY the Meridian 1 IP sets listed on page 2
• Must be connected to a properly-configured Layer 2 switch
• Must be installed within 1.4 m (5 feet) of an AC power source
Tools and Equipment Checklist
The 3300 CITELlink Gateway unit ships with mounting hardware and the 3300 CITELlink
Gateway Start Here Guide.
In addition, you will require:
Power supply cord.
Order the correct power cord for the country of installation from Mitel.
CAT 5 straight-through cable with RJ-45 connectors
A 25-pair extension line with Amphenol-type connectors for connecting the gateway to a
punchdown block. A female connector is required to connect to the unit’s front panel.
A punchdown block and phone cables
A PC with communications software (such as HyperTerminal) and an FTP utility
An RS-232 straight-through cable for connecting the PC to the gateway or 3300 ICP
controller
3300 ICP controller with Release 4.1 software or later
3300 ICP System Administration Tool username and password (for accessing the 3300
ICP System Administration Tool)
3300 ICP Device and User licenses for each Meridian 1 set
3300 CITELlink Phone User guides for the Meridian 1 sets
Note: For more information, see TABLE 5: Technical Specifications on page 21.
