5312/5324 IP Phone User Guide – Issue 2, June 2010 Page 5
Getting Started
Feature Buttons
Feature buttons provide quick access to commonly used features. See the following table for
descriptions.
Dialpad Buttons
Use the dialpad buttons to dial phone numbers, enter feature codes, and to enter characters
when using features that require text input.
Button Action
(Up) (Down) Provides volume control for the ringer, handset, and
speaker.
Scrolls through feature options.
(Speaker) Activates Handsfree Mode (speakerphone). See
“Using Handsfree Mode” on page 35.
Activates features.
(Mute) Temporarily turns off your microphone during a call.
(Directory) Activates the contact and feature Directory. See
“Using the Directory” on page 32.
(Special) Activates features while on a call. The (Special)
button does not cancel features. To cancel features,
press the Star button (
*).
Redial Calls the last external number dialed. You cannot
redial internal numbers.
(Hold) Places the current call on hold.
Left/backspace when entering dialpad characters.
See “Using the Dialpad Buttons to Enter Characters”
on page 17.
(Transfer) Transfers the current call.
Right/forward when entering dialpad characters. See
“Using the Dialpad Buttons to Enter Characters” on
page 17.
(Message) Connects to your voice mailbox and flashes to notify
you of waiting messages.
Toggles between Alpha Mode and Numeric Mode
when entering dialpad characters.

Mitel 5324 Specifications

Processor and Memory

processor type	TNETV1055 (MIPS)
processor speed	125 MHz
DSP speed	165 MHz
RAM	16 MB
ROM	8 MB

Weight and Dimensions

dimensions (phone only)	9.1 in x 7.5 in x 3.5 in (23 cm x 19 cm x 9 cm)
weight (phone only)	1.65 lbs or 0.75 kg
dimensions (packaged)	9.8 in x 8.3 in x 3.9 in (25 cm x 21 cm x 10 cm)
weight (packaged)	2.49 lbs or 1.13 kg
