5312/5324 IP Phone User Guide – Issue 2, June 2010 Page 17
Personalizing Your Phone
Using the Dialpad Buttons to Enter Characters
You can use the dialpad buttons to enter text or numbers for features such as Do-Not-Disturb
(see page 59) and Station Speed Dial (see page 34).
The following are guidelines when entering dialpad characters:
• Press (Message) to switch from Alpha Mode to Numeric Mode. The (Message)
button stays lit in Alpha Mode and is off in Numeric Mode.
• Press (Hold) to move the cursor to the left and delete characters.
• Press (Transfer) to move the cursor to the right.
• In Numeric Mode, press # for a hyphen (-).
• In Numeric Mode, press * for a colon (:).
• Press #, (Speaker), or lift and replace the handset to save entries.
To use the dialpad to enter characters:
Press the dialpad buttons as shown in the following table.
For example, to enter May 31, you could use the following sequence:
1. In Alpha Mode ( [Message] button is lit), press 6 once to enter an “M.”
2. Press 2 five times to enter an “a.”
3. Press 9 eight times to enter a “y.”
4. Press (Transfer) to enter a space.
5. Press (Message) to switch to Numeric Mode.
6. Press 3.
7. Press 1.
8. Press (Speaker), #, or lift the handset to save the entry.
Dialpad Characters — American English and British English
Number of Times Dialpad Button is Pressed
Button
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1
:-/,.;()&+*!?#1
2
ABC2ab c
3
DEF3d e f
4
GH I 4 g h i
5
JKL5 j k l
6
MNO 6mn o
7
PQRS7 p q r s
8
TUV8 t uv
9
WXYZ9wxyz
0
0

Mitel 5324 Specifications

Processor and Memory

processor type	TNETV1055 (MIPS)
processor speed	125 MHz
DSP speed	165 MHz
RAM	16 MB
ROM	8 MB

Weight and Dimensions

dimensions (phone only)	9.1 in x 7.5 in x 3.5 in (23 cm x 19 cm x 9 cm)
weight (phone only)	1.65 lbs or 0.75 kg
dimensions (packaged)	9.8 in x 8.3 in x 3.9 in (25 cm x 21 cm x 10 cm)
weight (packaged)	2.49 lbs or 1.13 kg
