5 DEBUG SUPPORT FUNCTION
5.2 Protocol Execution Log Storage Function (for Predefined Protocol only)
115
5
Checking with the buffer memory
Check the protocol execution logs in the execution log storage area.
1. The log registration condition can be set by the 'Execution log options' in the buffer memory (Un\G16610/16626) .
2. Execute the CPRTCL instruction.
3. Check the protocol execution logs stored in the execution log storage area (Un\G16643 to 18177/18435 to 19969).
For details, refer to the following section.
Page 498 Buffer memory list
1/0
b15 b0
0
0(OFF) :
1(ON) :
Buffer memory address
Log registration condition
Register failed protocols only.
Register all protocol
execution states and results.
Un\G16610/16626
