7 COMMUNICATIONS BY THE MODEM FUNCTION
7.4 Startup of the Modem Function
177
7
Register/read/delete data for initialization
The section explains the registration/reading/deletion of the data for initialization such as initialization commands for the
modem/TA connected to the C24 side for data communication with the target device using the modem function.
Details of the data for initialization
The following shows the registration destination and type of the data for initialization, registration number, and registration
count.
Up to 78 bytes of initialization commands can be registered as one data for initialization. (For 78 characters)
*1 For the priority of the registered data, refer to the following section.
Page 401 PARAMETER REGISTRATION TO CPU MODULE
Considerations for registration of data for initialization
• Do not include CR/LF (data code : 0DH/0AH) in the data for initialization to be registered to C24.
The CR/LF is output at the end of the AT command by C24 at the time of the initialization processing (automatically added).
• The registration status of the data for initialization stored in the flash ROM may be checked in the buffer memory (Un\G550
to 552).
For initial registration, register by designating an unregistered number.
When designating a registration number that has already been registered, first delete the registration data for the
designated number prior to registration.
Registration destination of
data for initialization
Types of data for
initialization that is
registered
Registration number of
data for initialization
Number of
registrations
Remarks
CPU module Built-in memory Arbitrary data for
initialization registered by
the user
*1
2500 to 2529 (9C4H to 9E1H) 30 • Register the data for initialization
after the debug process has been
completed.
• By registering data in this area,
replacing C24 can be performed
easily.
SD memory card Arbitrary data for
initialization registered by
the user
*1
2500 to 2529 (9C4H to 9E1H) 30 • Register the data for initialization
after the debug process has been
completed.
• By registering data in this area,
replacing C24 can be performed
easily.
C24 Flash ROM Data for initialization that
is registered before
shipment
2000 to 2013 (7D0H to 7DDH) 13 • Page 178 Registration contents
before shipment
Arbitrary data for
initialization registered by
the user
*1
2500 to 2529 (9C4H to 9E1H) 30 • Register the data for initialization
after the debug process has been
completed.
Buffer memory Arbitrary data for
initialization registered by
the user
–32767 to –32737 (8001H to
801FH)
31 • Register the data for initialization
before the debug process has been
completed.
