Mitsubishi AL-10MR-A Hardware Manual

α
Simple Application Controller
Hardware Specification 2
7
ENG
Table 2.5: Analog Input Specifications
Description Analog Input Specification
AL-10M*-D 6 Channels: I01 - I06
AL-20M*-D 8 Channels: I01 - I08
Analog Input Range 0 - 250
Resolution 10000/250 mv
Conversion Speed 10 ms
Input Voltage 0 - 10V DC
Input Impedance 150 kOhm or higher
Overall Accuracy +/- 5% (0.5V DC)
Offset/Gain
Offset Value = 0 at 0V DC
Gain Value: 0 - 10V = 0 - 250
These default values can be changed in the Offset FB
Temperature Drift +/- 3 LSB

Mitsubishi AL-10MR-A Specifications

General

Brand	Mitsubishi
Model	AL-10MR-A
Category	Controller
Language	English
