α
Simple Application Controller
Hardware Specification 2
8
ENG
2.4 Output Specification
Table 2.6:Relay Output Specifications
Description Relay Specification
Switched Voltage 250V AC~ or less, 30V DC or less
Max. Resistive Load (AL-6M** or AL-10M**) 8A/common (10A/common for 110V AC~ outputs)
Contact Life Cycle / Resistance Load
100,000 Cycles at 8 Amps / 240V AC~ or 24V DC
30,000 Cycles at 10 Amps / 110V AC~
Minimum Load 50mW (10mA at 5V DC)
Max. Inductive Load 245 VA (1/3 hp)/ 125 VAC~, 367 VA (1/2 hp) / 250 VAC~
Response Time 10ms or less
Operation Indication Liquid Crystal Display
Isolation Circuit By Relay
Table 2.7: Transistor Output Specifications (Source Type only)
Description Transistor Specification
Switched Voltage 5 - 24V DC (+20%, -5%)
Max. Resistive Load 1A / point (8 - 24V DC), 0.1A / point (5 - 8V DC)
Minimum Load 1.0mA
Max. Inductive Load 1A / 24V DC (24 W)
Max. Lamp Load 0.125 A / 24V DC (3.0 W)
Response Time On/Off, Off/On (approx) <
1 ms
Open Circuit Current Leakage <
0.1mA / 24V DC
Operation Indication Liquid Crystal Display
Isolation Circuit None
