α
Simple Application Controller
Wiring 4
18
ENG
4.6 Wiring Diagrams for the Sink/Source Terminals
4.6.1 Source (“+” Common) Input Wiring Diagram
4.6.2 Sink ("-" Common) Input Wiring Diagram
Table 4.3: Sink/Source Input Wiring
Ref. Item Description
1 DC Service Supply, 24V DC
2 DC Power Terminals
3 Sink/Source Input Wiring Terminals
4 Input Terminals
5 Sensor Input Switches
6 Analog Input
7
Circuit Protection Device - Limit to
1.0 Amps
!
+−
"
$
%
&
+−
(A) (B)
123
INPUTS
456
(
#
!
+−
"#
$
%
+−
(A) (B) 1 2 3
INPUTS
456
(
