Simple Application Controller
Hardware Specification 2
10
ENG
Insulation Resistance
7 Mohm at 500V DC per EN60730-1 between the following points:
Power/Input Terminals and Relay Output Terminals
Relay Output Terminal and Relay Output Terminal
All Terminals and the DIN 43880 Control box or equivalent
Type of Action EN 60730-1, Section 6.4.3 - Type 1C (Relay Output)
Type of Action EN 60730-1, Section 6.4.3 - Type 1Y (Transistor Output)
Software Class EN 60730-1, Section H6.18 - Class A
Construction of Control EN 60730-1, Section 6.15 - Incorporated Control
Whether the Control is electric EN 60730-1, Section H2.5.7 - Electric Control
Safety Class
II
Pollution Control For use in normal pollution situations
Grounding None
Electrical Isolation Reinforced primary/secondary insulation
Operation Ambience To be free of corrosive gases. Dust should be minimal.
Protection IP 20
Certifications CE, UL/cUL
Attestation of Conformity TÜV (AL-10MT-D, AL-10MR-D)
Complies with
UL 508
EN60730-1
EN61010-1
EN50081-1
EN50082-1
EN61000-6-2
Liquid Crystal Display
Will display 4 lines of ten characters per line, Program Run On/Off mode,
Password Protection, Image Table, and Function Blocks during programming.
Table 2.8:Environmental and Electrical Specifications
