Mitsubishi EHST20C-VM2C - 23. How to detach and attach the quick connection

100
PHOTOS & ILLUSTRATION
DISASSEMBLY PROCEDURE
O-ring
Plastic
bag
Female Male
O-ring
Photo 23-1
Photo 23-2
Photo 23-3
Photo 23-4
Photo 23-5
Photo 23-6 Photo 23-7 Photo 23-8
23. How to detach and attach the quick connection
Refertothefollowingstepswhendetachingandattachingthe
quick connection.
(1) Remove the clip. (Photos 23-1 and 23-2)
(2)SeparatetheconnectedpartstoremovetheO-ring.(Photo
23-3)
•DonotreusetheremovedO-ring.
•Wipeoffifdirtorforeignmattersarefoundonthesealing
surfacewheretheO-ringtouches.
(3)
ApplygreaseontheO-ringusingaplasticbag,etc.(Photo
23-4)
(4)AttachtheO-ringtothemalepartofquickconnection.(Pho-
to 23-5)
•KeeptheO-ringfreefromdirtorforeignmatters.
(5)
Connect the male and female parts of the quick connection.
(Photo 23-6)
(6) Attach the clip. (Photo 23-7)
•Ensuretoattachthewiderdiameterofthecliptothefe-
maleside.Failuretodosoitmaycausewaterleakatthe
connected part. (Photo 23-8) (For the same diameter
quickconnection,followingthisnoteisnotnecessary.)
Clip
Clip
Gap
Clip
OCH570C
