Mitsubishi EHST20C-VM2C User Manual

59
Output signal display (Request code: 175/553)
PleaserefertoTable2onrelevantwiringdiagramwhilstusingthefollowing.
Mixing valve state
OUT
Mixingvalvestate
5A 5B
0 0 Stop
0 1 Stop
1 0 Open
1 1 Close
0: OFF 1: ON
OUT
Display
8 * 9 10 11 12 13 14 15
0 0 0 0 0 0 0 0 00xx
1 0 0 0 0 0 0 0 01xx
0 1 0 0 0 0 0 0 02xx
1 1 0 0 0 0 0 0 03xx
0 0 1 0 0 0 0 0 04xx
1 0 1 0 0 0 0 0 05xx
0 1 1 0 0 0 0 0 06xx
1 1 1 0 0 0 0 0 07xx
0 0 0 1 0 0 0 0 08xx
1 0 0 1 0 0 0 0 09xx
0 1 0 1 0 0 0 0 0Axx
1 1 0 1 0 0 0 0 0Bxx
0 0 1 1 0 0 0 0 0Cxx
1 0 1 1 0 0 0 0 0Dxx
0 1 1 1 0 0 0 0 0Exx
1 1 1 1 0 0 0 0 0Fxx
0 0 0 0 1 0 0 0 10xx
1 0 0 0 1 0 0 0 11xx
0 1 0 0 1 0 0 0 12xx
1 1 0 0 1 0 0 0 13xx
0 0 1 0 1 0 0 0 14xx
1 0 1 0 1 0 0 0 15xx
0 1 1 0 1 0 0 0 16xx
1 1 1 0 1 0 0 0 17xx
0 0 0 1 1 0 0 0 18xx
1 0 0 1 1 0 0 0 19xx
0 1 0 1 1 0 0 0 1Axx
1 1 0 1 1 0 0 0 1Bxx
0 0 1 1 1 0 0 0 1Cxx
1 0 1 1 1 0 0 0 1Dxx
0 1 1 1 1 0 0 0 1Exx
1 1 1 1 1 0 0 0 1Fxx
0 0 0 0 0 1 0 0 20xx
1 0 0 0 0 1 0 0 21xx
0 1 0 0 0 1 0 0 22xx
1 1 0 0 0 1 0 0 23xx
0 0 1 0 0 1 0 0 24xx
1 0 1 0 0 1 0 0 25xx
0 1 1 0 0 1 0 0 26xx
1 1 1 0 0 1 0 0 27xx
0 0 0 1 0 1 0 0 28xx
1 0 0 1 0 1 0 0 29xx
0 1 0 1 0 1 0 0 2Axx
1 1 0
1 0 1 0 0 2
Bxx
0 0 1 1 0 1 0 0 2Cxx
1 0 1 1 0 1 0 0 2Dxx
0 1 1 1 0 1 0 0 2Exx
1 1 1 1 0 1 0 0 2Fxx
0 0 0 0 1 1 0 0 30xx
1 0 0 0 1 1 0 0 31xx
0 1 0 0 1 1 0 0 32xx
1 1 0 0 1 1 0 0 33xx
0 0 1 0 1 1 0 0 34xx
1 0 1 0 1 1 0 0 35xx
0 1 1 0 1 1 0 0 36xx
1 1 1 0 1 1 0 0 37xx
0 0 0 1 1 1 0 0 38xx
1 0 0 1 1 1 0 0 39xx
0 1 0 1 1 1 0 0 3Axx
1 1 0 1 1 1 0 0 3Bxx
0 0 1 1 1 1 0 0 3Cxx
1 0 1 1 1 1 0 0 3Dxx
0 1 1 1 1 1 0 0 3Exx
1 1 1 1 1 1 0 0 3Fxx
*Displayedonlywhentherequestcodeis553.
0: OFF 1: ON
OUT
Display
8 9 10 11 12 13 14 15
0 0 0 0 0 0 1 0 40xx
1 0 0 0 0 0 1 0 41xx
0 1 0 0 0 0 1 0 42xx
1 1 0 0 0 0 1 0 43xx
0 0 1 0 0 0 1 0 44xx
1 0 1 0 0 0 1 0 45xx
0 1 1 0 0 0 1 0 46xx
1 1 1 0 0 0 1 0 47xx
0 0 0 1 0 0 1 0 48xx
1 0 0 1 0 0 1 0 49xx
0 1 0 1 0 0 1 0 4Axx
1 1 0 1 0 0 1 0 4Bxx
0 0 1 1 0 0 1 0 4Cxx
1 0 1 1 0 0 1 0 4Dxx
0 1 1 1 0 0 1 0 4Exx
1 1 1 1 0 0 1 0 4Fxx
0 0 0 0 1 0 1 0 50xx
1 0 0 0 1 0 1 0 51xx
0 1 0 0 1 0 1 0 52xx
1 1 0 0 1 0 1 0 53xx
0 0 1 0 1 0 1 0 54xx
1 0 1 0 1 0 1 0 55xx
0 1 1 0 1 0 1 0 56xx
1 1 1 0 1 0 1 0 57xx
0 0 0 1 1 0 1 0 58xx
1 0 0 1 1 0 1 0 59xx
0 1 0 1 1 0 1 0 5Axx
1 1 0 1 1 0 1 0 5Bxx
0 0 1 1 1 0 1 0 5Cxx
1 0 1 1 1 0 1 0 5Dxx
0 1 1 1 1 0 1 0 5Exx
1 1 1 1 1 0 1 0 5Fxx
0 0 0 0 0 1 1 0 60xx
1 0 0 0 0 1 1 0 61xx
0 1 0 0 0 1 1 0 62xx
1 1 0 0 0 1 1 0 63xx
0 0 1 0 0 1 1 0 64xx
1 0 1 0 0 1 1 0 65xx
0 1 1 0 0 1 1 0 66xx
1 1 1 0 0 1 1 0 67xx
0 0 0 1 0 1 1 0 68xx
1 0 0 1 0 1 1 0 69xx
0 1 0 1 0 1 1 0 6Axx
1 1 0
1 0 1 1 0 6
Bxx
0 0 1 1 0 1 1 0 6Cxx
1 0 1 1 0 1 1 0 6Dxx
0 1 1 1 0 1 1 0 6Exx
1 1 1 1 0 1 1 0 6Fxx
0 0 0 0 1 1 1 0 70xx
1 0 0 0 1 1 1 0 71xx
0 1 0 0 1 1 1 0 72xx
1 1 0 0 1 1 1 0 73xx
0 0 1 0 1 1 1 0 74xx
1 0 1 0 1 1 1 0 75xx
0 1 1 0 1 1 1 0 76xx
1 1 1 0 1 1 1 0 77xx
0 0 0 1 1 1 1 0 78xx
1 0 0 1 1 1 1 0 79xx
0 1 0 1 1 1 1 0 7Axx
1 1 0 1 1 1 1 0 7Bxx
0 0 1 1 1 1 1 0 7Cxx
1 0 1 1 1 1 1 0 7Dxx
0 1 1 1 1 1 1 0 7Exx
1 1 1 1 1 1 1 0 7Fxx
OCH570C
