Mitsubishi EHST20C-VM2C User Manual

9
●
Wireless Remote Controller PAR-WT50R-E
●
Remote Sensor PAC-SE41TS-E *1
Volumeofsanitarywatercircuit,primaryDHWcircuit(from3-wayvalvetoconuentpointwithheatingcircuit),pipingtoexpansionvessel,andexpansionvesselarenotincludedinthisvalue.
●
Wireless Receiver PAR-WR51R-E
●
Thermistor PAC-TH011-E *2 The environment must be frost-free.
●
Immersion heater (1Ph 3 kW) PAC-IH03V2-E
●
Hightemperaturethermistor PAC-TH011HT-E *3Coolingmodeisnotavailableinlowoutdoortemperature.
●
EHPT Accessories for UK PAC-WK01UK-E
●
ecodan Wi-Fi Interface PAC-WF010-E Ifyouuseoursystemincoolingmodeatthelowambienttemperature(10°Corbelow),therearesomerisksofplateheatexchangerbreakingbyfrozenwater.
●
Drain pan stand PAC-DP01-E
●
2-zonekit PAC-TZ01-E *4Forthemodelwithoutbothboosterheaterandimmersionheater,themaximumallowablehotwatertemperatureis[Maximumoutletwaterofoutdoorunit−3°C]
Forthemaximumoutletwaterofoutdoorunit,refertooutdoorunitdatabook.
*5 Tested under BS7206 conditions. *6 Donottimmersionheaterswithoutthermalcut-out.
Model name (Service Ref.)
EHST20C-
VM2CR1.UK
EHST20C-
VM6CR1.UK
EHST20C-
YM9CR1.UK
EHST20C-
TM9CR1.UK
EHST20C-
VM2ECR1.UK
EHST20C-
VM6ECR1.UK
EHST20C-
YM9ECR1.UK
EHST20C-
MECR1.UK
EHST20D-
VM2CR1.UK
EHST20D-
MECR1.UK
EHST20D-
MHCR1.UK
EHST20D-
VM2ECR1.UK
EHST20D-
YM9CR1.UK
EHST20C-
VM2CR2.UK
EHST20C-
VM6CR2.UK
EHST20C-
YM9CR2.UK
EHST20C-
TM9CR2.UK
EHST20C-
VM2ECR2.UK
EHST20C-
VM6ECR2.UK
EHST20C-
YM9ECR2.UK
EHST20C-
MECR2.UK
EHST20D-
VM2CR2.UK
EHST20D-
MECR2.UK
EHST20D-
MHCR2.UK
EHST20D-
VM2ECR2.UK
EHST20D-
YM9CR2.UK
Nominaldomestichotwatervolume 200 L Overall unit dimensions 1600×595×680mm(Height×Width×Depth) Weight(empty) 110kg 111kg 112kg 112kg 104kg 105kg 106kg 103kg 103kg 96kg 103kg 97kg 105kg
Weight(full) 320kg 321kg 322kg 322kg 314kg 315kg 316kg 313kg 312kg 305kg 312kg 306kg 314kg
Watervolumeofheatingcircuitintheunit*1 6.6kg 6.6kg 6.6kg 6.6kg 6.6kg 6.6kg 6.6kg 6.6kg 5.7kg 5.7kg 5.7kg 5.7kg 5.7kg
Plateheatexchanger(MWA2)
— — — — —
Plateheatexchanger(MWA1) — — — — — — — —
Unventedexpansion vessel(Primaryheating)
Nominal volume 12 L — — — — 12 L — 12 L — 12 L
Chargepressure 1 bar — — — — 1 bar — 1 bar — 1 bar
Safety device
Water circuit
(Primary)
Control thermistor
Heating 1–80°C
Pressure relief valve 0.3 MPa (3bar) Flowsensor Min.ow5.0L/min
Booster heater
Manual reset thermostat 90°C — 90°C — — 90°C
Thermal Cut-out (for dry run prevention) 121°C — 121°C — — 121°C
DHW tank
Control thermistor 40–70°C Temperature and pressure relief valve/ Pressure relief valve
1.0 MPa
(10 bar)
PrimarycircuitcirculatingPump Grundfos UPM2 15-70 130 SanitarycircuitcirculatingPump Grundfos UPSO 15-60 130 CIL2 Connections
Water 28 mm compression primary circuit/22 mm compression DHW circuit
Refrigerant (R410A)
Liquid 9.52 mm 6.35 mm Gas 15.88 mm 12.7 mm
Targettemperature range
Flowtem- perature
Heating 25–60°C Cooling —
Room tem- perature
Heating 10–30°C Cooling —
Guaranteed operatingrange
Ambient *2 0–35°C(
80 %RH)
Outdoor temperature
Heating See outdoor unit spec table. Cooling —
DHW tank performance
Maximumallowablehotwatertemperature
70°C *4 70°C *4 70°C
TimetoraiseDHWtanktemp.15–65°C*5
22.75 min
Timetoreheat70%ofDHWtankto65°C*5
17.17 min
Electrical data
Control board
Powersupply (Phase,voltage,frequency)
~/N,230V,50Hz
Breaker(whenpowered from independent source)
10A
Booster heater
Powersupply (Phase,voltage,frequency)
~/N, 230 V,
50Hz
~/N, 230 V,
50Hz
3~, 400 V,
50Hz
3~, 230 V,
50Hz
~/N, 230 V,
50Hz
~/N, 230 V,
50Hz
3~, 400 V,
50Hz
—
~/N, 230 V,
50Hz
— —
~/N, 230 V,
50Hz
3~, 400 V,
50Hz
Capacity 2 kW 2 kW+4 kW 3 kW+6 kW 3 kW+6 kW 2 kW 2 kW+4 kW 3 kW+6 kW — 2 kW — — 2 kW 3 kW+6 kW
Current 9 A 26 A 13 A 23 A 9 A 26 A 13 A — 9 A — — 9 A 13 A
Breaker 16 A 32 A 16 A 32 A 16 A 32 A 16 A — 16 A — — 16 A 16 A
Immersion heater *6
Powersupply (Phase,voltage,frequency)
—
~/N, 230 V,
50Hz
—
Capacity — 3 kW — Current — 13 A — Breaker — 16 A —
Sound pressure level 28 dB(A) Soundpowerlevel 40 dB(A)
Optional extras
OCH570C
