Mitsubishi FR-E520-0.1KN

PARAMETERS
69
Func-
tion
Para-
meter
Number
Name
Setting
Range
Minimum
Setting
Increments
Factory
Setting
Refer
To:
Custo-
mer
setting
24
Multi-speed setting
(speed 4)
0 to 400Hz,
9999
0.01Hz 9999 79
25
Multi-speed setting
(speed 5)
0 to 400Hz,
9999
0.01Hz 9999 79
26
Multi-speed setting
(speed 6)
0 to 400Hz,
9999
0.01Hz 9999 79
27
Multi-speed setting
(speed 7)
0 to 400Hz,
9999
0.01Hz 9999 79
29
Acceleration/
deceleration pattern
0, 1, 2 1 0 88
30
Regenerative function
selection
0, 1 1 0 89
31 Frequency jump 1A
0 to 400Hz,
9999
0.01Hz 9999 90
32 Frequency jump 1B
0 to 400Hz,
9999
0.01Hz 9999 90
33 Frequency jump 2A
0 to 400Hz,
9999
0.01Hz 9999 90
34 Frequency jump 2B
0 to 400Hz,
9999
0.01Hz 9999 90
35 Frequency jump 3A
0 to 400Hz,
9999
0.01Hz 9999 90
36 Frequency jump 3B
0 to 400Hz,
9999
0.01Hz 9999 90
Standard operation functions
37 Speed display
0, 0.01 to
9998
0.001 r/min 0 91
41
Up-to-frequency
sensitivity
0 to 100% 0.1% 10% 92
42
Output frequency
detection
0 to 400Hz 0.01Hz 6Hz 92
Output Terminal
functions
43
Output frequency
detection for reverse
rotation
0 to 400Hz,
9999
0.01Hz 9999 92
44
Second acceleration/
deceleration time
0 to 3600 s/
0 to 360 s
0.1 s/
0.01 s
5 s 80
45
Second deceleration
time
0 to 3600 s/
0 to 360 s,
9999
0.1 s/
0.01 s
9999 80
46
Second torque boost
(Note 1)
0 to 30%,
9999
0.1% 9999 76
47
Second V/F
(base frequency)
(Note 1)
0 to 400Hz,
9999
0.01Hz 9999 78
Sond functions
48
Second electronic
overcurrent protection
0 to 500A,
9999
0.01A 9999 82
Parameter List
4
