Mitsubishi FX3G Series Programming Manual

16
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
Related manuals
U
Supplied
with product
FX3U-485-BD
Installation Manual
JY997D13001
Handling procedures of the RS-485 communication
expansion board.
For use, refer to the FX Series User’s Manual -
Data Communication Edition.
−
U
Supplied
with product
FX
3U-485ADP
Installation Manual
JY997D13801
Handling procedures of the RS-485 communication
special adapter.
For use, refer to the FX Series User’s Manual -
Data Communication Edition.
−
U
Supplied
with product
FX
3U-485ADP-MB
Installation Manual
JY997D26301
Handling procedures of the RS-485 communication
special adapter.
For the MODBUS serial communication network,
refer to the FX
3G/FX3U/FX3GC/FX3UC Series
User’s Manual - MODBUS Serial Communication
Edition.
For N:N Network, parallel link, computer link or non-
protocol communication by RS and RS2
instructions, refer to the FX Series User’s Manual -
Data Communication Edition.
−
U
Supplied
with product
FX-485PC-IF
Hardware Manual
JY992D81801
Handling procedures of the RS-232C/RS-485
conversion interface.
For use, refer to the FX Series User’s Manual -
Data Communication Edition.
−
CC-Link, MELSEC I/O LINK and AS-i system
When using each product, refer also to the User’s Manual - Hardware Edition of the PLC main unit to which each product is
connected.
U
Supplied
with product
FX
3U-16CCL-M
Installation Manual
JY997D43401
Handling procedures of the CC-Link master special
function block.
For use, refer to the FX3U-16CCL-M User’s
Manual.
−
{
Additional
Manual
FX3U-16CCL-M
User’s Manual
JY997D43601
Details about the CC-Link master special function
block.
09R724
U
Supplied
with product
FX2N-16CCL-M
Hardware Manual
JY992D93201
Handling procedures of the CC-Link master special
function block.
For use, refer to the FX2N-16CCL-M User’s
Manual.
−
{
Additional
Manual
FX2N-16CCL-M
User’s Manual
JY992D93101
Details about the CC-Link master special function
block.
09R710
U
Supplied
with product
FX3U-64CCL
Installation Manual
JY997D29801
Handling procedures of the CC-Link interface
special function block.
For use, refer to the FX3U-64CCL User’s Manual.
−
{
Additional
Manual
FX3U-64CCL
User’s Manual
JY997D30401
Handling procedures of the CC-Link interface
special function block.
09R718
{
Supplied
with product
FX2N-32CCL
User’s Manual
JY992D71801
Handling procedures of the CC-Link remote device
station special function block.
09R711
{
Supplied
with product
Remote I/O station, remote
device station and intelligent
device station for CC-Link
As for the remote I/O station, remote device station and intelligent
device station for CC-Link, refer to each manual and the related data.
U
Supplied
with product
FX2N-64CL-M
User’s Manual
[Hardware Volume]
JY997D05401
Handling procedures of the CC-Link/LT master
special function block.
For use, refer to the FX2N-64CL-M User’s Manual
[Detailed Volume].
−
{
Additional
Manual
FX2N-64CL-M
User’s Manual
[Detailed Volume]
JY997D08501
Details about the CC-Link/LT master special
function block.
−
{
Supplied
with product
Remote I/O station, remote
device station, power supply
adapter and dedicated power
supply for CC-Link/LT
As for the remote I/O station, remote device station, power supply
adapter and dedicated power supply for CC-Link/LT, refer to each
manual and the related data.
{
Supplied
with product
FX2N-16LNK-M
User's Manual
JY992D73701
Handling procedure of the master special function
block for the MELSEC I/O LINK
09R709
{
Supplied
with product
FX
2N-32ASI-M
User’s Manual
JY992D76901
Handling procedure of the master special function
block for the AS-i system.
−
Manuals for analog control
Common
{
Additional
Manual
FX3G/FX3U/FX3GC/FX3UC
User’s Manual
- Analog Control Edition
JY997D16701
Detaileds about the analog special function block
(FX3U-4AD, FX3U-4DA, FX3UC-4AD) and analog
special adapter (FX3U-∗∗∗∗-ADP).
09R619
~Essential manual
{Manual required depending on application
UManual with additional manual for detailed explanation
Manual name
Manual
number
Contents
Model name
code
