FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
Related manuals
Analog input, temperature input and temperature control
When using each product, refer also to the User’s Manual - Hardware Edition of the PLC main unit to which each product is
connected.
U
Supplied
with product
FX3G-2AD-BD
Installation Manual
JY997D33501
Handling procedures of the 2-channel analog input
expansion board.
For use refer to the FX3G/FX3U/FX3GC/FX3UC
Series User’s Manual - Analog Control Edition.
−
{
Supplied
with product
FX2N-2AD
User’s Guide
JY992D74701
Handling procedures of the 2-channel analog input
special function block.
−
U
Supplied
with product
FX3U-4AD
Installation Manual
JY997D20701
Handling procedures of the 4-channel analog
input special function block.
For use refer to the FX
3G/FX3U/FX3GC/FX3UC
Series User’s Manual - Analog Control Edition.
−
U
Supplied
with product
FX3U-4AD-ADP
Installation Manual
JY997D13901
Handling procedures of the 4-channel analog input
special adapter.
For use, refer to the FX3G/FX3U/FX3GC/FX3UC
Series User’s Manual - Analog Control Edition.
−
U
Supplied
with product
FX3UC-4AD
Installation Manual
JY997D14901
Handling procedures of the 4-channel analog
input special function block.
For use refer to the FX3G/FX3U/FX3GC/FX3UC
Series User’s Manual - Analog Control Edition.
−
{
Supplied
with product
FX2N-4AD
User’s Guide
JY992D65201
Handling procedures of the 4-channel analog input
special function block.
−
{
Supplied
with product
FX
2NC-4AD
User’s Manual
JY997D07801
Handling procedures of the 4-channel analog input
special function block.
−
{
Supplied
with product
FX2N-8AD
User’s Manual
JY992D86001
Handling procedures of the 8-channel analog input
(and thermocouple input) special function block.
09R608
U
Supplied
with product
FX3U-4AD-PT-ADP
User’s Manual
JY997D14701
Handling procedures of the 4-channel Pt100
temperature sensor input special adapter.
For use, refer to the FX3G/FX3U/FX3GC/FX3UC
Series User’s Manual - Analog Control Edition.
−
U
Supplied
with product
FX3U-4AD-PTW-ADP
User’s Manual
JY997D29101
Handling procedures of the 4-channel Pt100
temperature sensor input special adaptor.
For use, refer to the FX
3G
/FX
3U/FX3GC
/FX
3UC
Series User
’
s Manual - Analog Control Edition.
−
{
Supplied
with product
FX
2N-4AD-PT
User’s Guide
JY992D65601
Handling procedures of the 4-channel Pt100
temperature sensor input special function block.
−
U
Supplied
with product
FX3U-4AD-PNK-ADP
User’s Manual
JY997D29201
Handling procedures of the 4-channel
Pt1000/Ni1000 temperature sensor input special
adaptor.
For use, refer to the FX
3G
/FX
3U/FX3GC
/FX
3UC
Series User
’
s Manual - Analog Control Edition.
−
U
Supplied
with product
FX
3U-4AD-TC-ADP
User’s Manual
JY997D14801
Handling procedures of the 4-channel
thermocouple input special adapter.
For use, refer to the FX3G/FX3U/FX3GC/FX3UC
Series User’s Manual - Analog Control Edition.
−
{
Supplied
with product
FX2N-4AD-TC
User’s Guide
JY992D65501
Handling procedures of the 4-channel
thermocouple input special function block.
−
U
Supplied
with product
FX3U-4LC
Installation Manual
JY997D38901
Handling procedures of the 4-channel temperature
control special function block.
For use, refer to the FX
3U-4LC User’s Manual
−
{
Additional
Manual
FX3U-4LC
User’s Manual
JY997D39101
Detail about the 4-channel temperature control
special function block.
09R625
U
Supplied
with product
FX2N-2LC
User’s Guide
JY992D85601
Handling procedures of the 2-channel temperature
control special function block.
For use, refer to the FX
2N-2LC User’s Manual.
−
{
Additional
Manual
FX2N-2LC
User’s Manual
JY992D85801
Details about the 2-channel temperature control
special function block.
09R607
~Essential manual
{Manual required depending on application
UManual with additional manual for detailed explanation
Manual name
Manual
number
Contents
Model name
code
