FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
37 Operation of Special Devices (M8000 -, D8000 -)
37.1 Special Device List (M8000 -, D8000 -)
High-Speed Counter Comparison, High-Speed Table, and Positioning [Positioning is supported in FX3G, FX3GC, FX1S, FX1N, and FX1NC
PLCs.]
[D]8130
HSZ (FNC 55) instruction:
High-speed comparison table counter
– – 3 3 M8130 – – 3 – 3
[D]8131
HSZ (FNC 55) and PLSY (FNC 57) instructions:
Speed pattern table counter
– – 3 3 M8132 – – 3 – 3
[D]8132 Lower
HSZ (FNC 55) and PLSY (FNC 57)
instructions: Speed pattern frequency
– – 3 3 M8132 – – 3 – 3
[D]8133 Upper
[D]8134 Lower HSZ (FNC 55) and PLSY (FNC 57)
instructions:
Number of target pulses for speed pattern
– – 3 3 M8132 – – 3 – 3
[D]8135 Upper
D 8136 Lower PLSY (FNC 57), PLSR (FNC 59)
instructions:
Accumulated total number of pulses output
to Y000 and Y001
3 3 3 3 – 3333 3
D 8137 Upper
[D]8138 HSCT (FNC280) instruction: Table counter
– – 3 3 M8138 – – – – –
[D]8139
HSCS (FNC 53), HSCR (FNC 54), HSZ (FNC 55),
and HSCT (FNC280) instructions:
Number of instructions being executed
– – 3 3 M8139 – – – – –
D 8140 Lower
Accumulated number of pulses output from
Y000 for PLSY (FNC 57) and PLSR (FNC
59) instructions.
3 3 3 3 – 3333 3
D 8141 Upper
D 8142 Lower
Accumulated number of pulses output from
Y001 for PLSY (FNC 57) and PLSR (FNC
59) instructions.
3 3 3 3 – 3333 3
D 8143 Upper
[D]8144 Not used
– – – – – –––– –
D 8145
ZRN (FNC156), DRVI (FNC158), and DRVA
(FNC159) instructions:
Bias speed
Default: 0
– – – ––33 – 3 –
D 8146 Lower
ZRN (FNC156), DRVI (FNC158),
and DRVA (FNC159) instructions:
Maximum speed
• Default in FX1S and FX1N: 100000
• Default in FX1NC: 100000
*1
– – – ––33 –
3
*1
–
D 8147 Upper
D 8148
ZRN (FNC156), DRVI (FNC158), and DRVA
(FNC159) instructions:
Acceleration/deceleration time
Default: 100
– – – ––33 – 3 –
[D]8149 Not used – – – – – –––– –
*1. Must be changed to 10000 or less by PLC program.
Number and name Content of register
Applicable model
FX 3G FX 3GC FX 3U FX 3UC
Correspond-
ing special
device
FX 1S FX 1N FX 2N FX 1NC FX 2NC
