FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
37 Operation of Special Devices (M8000 -, D8000 -)
37.2 Supplement of Special Devices (M8000 - and D8000 -)
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
•FX3G/FX3GC PLCs
*1. Can be connected only to FX3G PLC (40-point and 60-point type) and FX3GC PLC.
Number
Operation and function
FX3U-4AD-ADP FX3U-4DA-ADP FX3U-3A-ADP
Applicable
version
Ver. 1.00 or later Ver. 1.00 or later Ver. 1.20 or later
1st analog special adapter
M 8280 Input mode switching Ch1 Output mode switching Ch1 Input mode switching Ch1
M 8281
Input mode switching Ch2 Output mode switching Ch2 Input mode switching Ch2
M 8282
Input mode switching Ch3 Output mode switching Ch3 Output mode switching
M 8283
Input mode switching Ch4 Output mode switching Ch4 Not used
M 8284 Not used Output hold mode cancel Ch1 Not used
M 8285
Not used Output hold mode cancel Ch2 Not used
M 8286
Not used Output hold mode cancel Ch3 Output hold mode cancel
M 8287
Not used Output hold mode cancel Ch4 Sets whether or not input channel 1 is used.
M 8288
Not used Not used Sets whether or not input channel 2 is used.
M 8289
Not used Not used Sets whether or not output channel is used.
2nd analog special adapter
*1
M 8290 Input mode switching Ch1 Output mode switching Ch1 Input mode switching Ch1
M 8291
Input mode switching Ch2 Output mode switching Ch2 Input mode switching Ch2
M 8292
Input mode switching Ch3 Output mode switching Ch3 Output mode switching
M 8293 Input mode switching Ch4 Output mode switching Ch4 Not used
M 8294
Not used Output hold mode cancel Ch1 Not used
M 8295
Not used Output hold mode cancel Ch2 Not used
M 8296
Not used Output hold mode cancel Ch3 Output hold mode cancel
M 8297
Not used Output hold mode cancel Ch4 Sets whether or not input channel 1 is used.
M 8298
Not used Not used Sets whether or not input channel 2 is used.
M 8299 Not used Not used Sets whether or not output channel is used.
Number
Operation and function
FX3U-4AD-PT(W)-ADP FX3U-4AD-TC-ADP FX3U-4AD-PNK-ADP
Applicable
version
Ver. 1.00 or later Ver. 1.00 or later Ver. 1.00 or later
1st analog special adapter
M 8280 Temperature unit selection Temperature unit selection Temperature unit selection
M 8281 Not used Type-K/-J switching Input sensor selection
M 8282 Not used Not used Not used
M 8283
Not used Not used Not used
M 8284
Not used Not used Not used
M 8285
Not used Not used Not used
M 8286
Not used Not used Not used
M 8287
Not used Not used Not used
M 8288
Not used Not used Not used
M 8289
Not used Not used Not used
2nd analog special adapter
*1
M 8290 Temperature unit selection Temperature unit selection Temperature unit selection
M 8291 Not used Type-K/-J switching Input sensor selection
M 8292 Not used Not used Not used
M 8293
Not used Not used Not used
M 8294
Not used Not used Not used
M 8295
Not used Not used Not used
M 8296
Not used Not used Not used
M 8297
Not used Not used Not used
M 8298
Not used Not used Not used
M 8299
Not used Not used Not used

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
