Mitsubishi FX3G Series Programming Manual

864
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
37 Operation of Special Devices (M8000 -, D8000 -)
37.2 Supplement of Special Devices (M8000 - and D8000 -)
2. Special data registers (D8260 to D8299)
•FX3U/FX3UC PLC
*1. In the case of FX3U PLCs, all versions are applicable.
Number
Operation and function
FX3U-4AD-ADP FX3U-4DA-ADP FX3U-3A-ADP
Applicable
version
Ver. 1.20 or later
*1
Ver. 1.20 or later
*1
Ver. 2.61 or later
1st analog special adapter
D 8260 Input data Ch1 Output data Ch1 Input data Ch1
D 8261
Input data Ch2 Output data Ch2 Input data Ch2
D 8262
Input data Ch3 Output data Ch3 Output data
D 8263
Input data Ch4 Output data Ch4 Not used
D 8264
Number of averaging times
for Ch1 (1 to 4095)
Not used
Number of averaging times
for Ch1 (1 to 4095)
D 8265
Number of averaging times
for Ch2 (1 to 4095)
Not used
Number of averaging times
for Ch2 (1 to 4095)
D 8266
Number of averaging times
for Ch3 (1 to 4095)
Not used Not used
D 8267
Number of averaging times
for Ch4 (1 to 4095)
Not used Not used
D 8268 Error status Error status Error status
D 8269 Model code: K1 Model code: K2 Model code: K50
2nd analog special adapter
D 8270 Input data Ch1 Output data Ch1 Input data Ch1
D 8271
Input data Ch2 Output data Ch2 Input data Ch2
D 8272
Input data Ch3 Output data Ch3 Output data
D 8273
Input data Ch4 Output data Ch4 Not used
D 8274
Number of averaging times
for Ch1 (1 to 4095)
Not used
Number of averaging times
for Ch1 (1 to 4095)
D 8275
Number of averaging times
for Ch2 (1 to 4095)
Not used
Number of averaging times
for Ch2 (1 to 4095)
D 8276
Number of averaging times
for Ch3 (1 to 4095)
Not used Not used
D 8277
Number of averaging times
for Ch4 (1 to 4095)
Not used Not used
D 8278 Error status Error status Error status
D 8279 Model code: K1 Model code: K2 Model code: K50
3rd analog special adapter
D 8280 Input data Ch1 Output data Ch1 Input data Ch1
D 8281
Input data Ch2 Output data Ch2 Input data Ch2
D 8282
Input data Ch3 Output data Ch3 Output data
D 8283
Input data Ch4 Output data Ch4 Not used
D 8284
Number of averaging times
for Ch1 (1 to 4095)
Not used
Number of averaging times
for Ch1 (1 to 4095)
D 8285
Number of averaging times
for Ch2 (1 to 4095)
Not used
Number of averaging times
for Ch2 (1 to 4095)
D 8286
Number of averaging times
for Ch3 (1 to 4095)
Not used Not used
D 8287
Number of averaging times
for Ch4 (1 to 4095)
Not used Not used
D 8288 Error status Error status Error status
D 8289
Model code: K1 Model code: K2 Model code: K50
4th analog special adapter
D 8290 Input data Ch1 Output data Ch1 Input data Ch1
D 8291
Input data Ch2 Output data Ch2 Input data Ch2
D 8292
Input data Ch3 Output data Ch3 Output data
D 8293
Input data Ch4 Output data Ch4 Not used
D 8294
Number of averaging times
for Ch1 (1 to 4095)
Not used
Number of averaging times
for Ch1 (1 to 4095)
D 8295
Number of averaging times
for Ch2 (1 to 4095)
Not used
Number of averaging times
for Ch2 (1 to 4095)
D 8296
Number of averaging times
for Ch3 (1 to 4095)
Not used Not used
D 8297
Number of averaging times
for Ch4 (1 to 4095)
Not used Not used
D 8298 Error status Error status Error status
D 8299
Model code: K1 Model code: K2 Model code: K50

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
