FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
A Programming Tool Applicability and Version Upgrade History
A-1 Programming Tool Applicability
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
c) FX3UC PLC
*1. Select "FX3UC" in model selection for GX Developer Ver. 8.24A.
*2. Ver. 8.89T and later versions support the baud rate "38400 bps" in the communication setting for RS
and RS2 instructions, inverter communication and computer link.
• GX Developer Japanese version (SWD5C-GPPW-J) is applicable to FX3G/FX3U/FX3UC PLCs from the
following versions. Select "FX3G" in model selection when creating a program for an FX3GC PLC.
a) FX3G PLC
b) FX3U PLC
c) FX3UC PLC
*3. Select "FX3UC" in model selection for GX Developer Ver. 8.23Z or Ver. 8.24A.
*4. Ver. 8.88S and later versions support the baud rate "38400 bps" in the communication setting for RS
and RS2 instructions, inverter communication and computer link.
FX3UC PLC version
Model name
(Media model name
is shown below.)
Applicable GX Developer
version
Remarks
Before Ver. 2.20
GX Developer
SWD5C-GPPW-E
Ver. 8.18U or later • Model selection: FX3U(C)
Before Ver. 2.30 Ver. 8.24A or later
• Model selection: FX3U(C)
*1
Before Ver. 2.41 Ver. 8.29F or later
• Model selection: FX3U(C)
Before Ver. 2.53
Ver. 8.29F or later
*2
Before Ver. 2.61
Ver. 8.68W or later
*2
Ver. 2.61
Ver. 8.82L or later
*2
FX3G PLC version
Model name
(Media model name
is shown below.)
Applicable GX Developer
version
Remarks
Before Ver. 1.10
GX Developer
SWD5C-GPPW-J
Ver. 8.72A or later
• Model selection: FX3G
Ver. 1.10 Ver. 8.76E or later
FX3U PLC version
Model name
(Media model name
is shown below.)
Applicable GX Developer
version
Remarks
Before Ver. 2.30
GX Developer
SWD5C-GPPW-J
Ver. 8.23Z or later
• Model selection: FX3U(C)
*3
Before Ver. 2.41 Ver. 8.29F or later
• Model selection: FX3U(C)
Before Ver. 2.61
Ver. 8.29F or later
*4
Ver. 2.61
Ver. 8.82L or later
*4
FX3UC PLC version
Model name
(Media model name
is shown below.)
Applicable GX Developer
version
Remarks
Before Ver. 1.30
GX Developer
SWD5C-GPPW-J
Ver. 8.13P or later
• Model selection: FX3UC
Before Ver. 2.20 Ver. 8.18U or later
Before Ver. 2.30 Ver. 8.23Z or later
• Model selection: FX3U(C)
*3
Before Ver. 2.41 Ver. 8.29F or later
• Model selection: FX3U(C)
Before Ver. 2.53
Ver. 8.29F or later
*4
Before Ver. 2.61
Ver. 8.68W or later
*4
Ver. 2.61
Ver. 8.82L or later
*4

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
