Mitsubishi MELSEC-A series Programming Manual

6. BASIC INSTRUCTIONS
6 − 55
MELSEC-A
FMOV
(1) Program which outputs the data of the lower 4 bits of D0 to Y10 to 23 in units of
4 points when XA turn on.
(2) Program which outputs the data of X20 to X23 to D100 to D103 when XA is
turned on.
• Coding
0 LD X00A
1 FMOVP D0 K1Y010 K5
10 END
0
P K1 K
FMOV D0 Y010 5
X00A
• Coding
0 LD X00A
1 FMOVP K1X020 D100 K4
10 END
0
P K1 K
FMOV X020 D100 4
X00A
Before
execution
Ignored.
After execution
(
destination
)
Turn to 0.
4
p
cs.
(
S
)
(
D
)
5
p
cs.
Ignored
Transfer
