Mitsubishi MELSEC-A series Programming Manual

8. MICROCOMPUTER MODE
8 − 13
MELSEC-A
Device
CPU
Type
Address Configuration
Special
relay (M)
8740
H
to
875F
H
M9000
to
9255
Timer (T)
contact
8780
H
to
879F
H
T0 to 255
Counter
(C)
contact
87C0H
to
87DF
H
C0 to 255
Timer (T)
coil
9C00
H
to
9C1F
H
T0 to 255
Counter
(C) coil
A3H
A3M
9C40
H
to
9C5F
H
C0 to 255
• Stores PC operation results and
allows read/write.
8400
H
8402
H
8404
H
• Stores device ON/OFF data in one bit locations.
• 0 indicates OFF and 1 ON.
Example: M0 to 47 are as follows:
Odd address Even address
