APPENDICES
APP − 46
MELSEC-A
Table 2.1 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
AnS A1SJH/A1SH A2SH (S1)
Instruction Condition (Device)
R D R D R D
Unexecuted 59 61 16.8 16.8 11.7 13.7
ON 62 63 17.2 17.2 11.6 13.7
Y
Executed
OFF 60 62 17.2 17.2 11.7 13.7
Unexecuted 59 59 15.2 15.2 11.7 11.7
ON 62 62 15.6 15.6 11.6 11.6
PLS
PLF
M, L, B, F
Executed
OFF 61 61 15.6 15.6 11.7 11.6
Unexecuted 3.0 3.0 1.4 1.4 1.0 1.0
Y
Executed 38 39 12.4 12.4 8.1 10.1
Unexecuted 3.0 3.0 1.4 1.4 1.0 1.0
SET
SFTP
M, L, B, F
Executed 38 38 10.8 10.8 8.1 8.1
MPS  1.0 1.0 0.33 0.33 0.25 0.25
MRD  1.0 1.0 0.33 0.33 0.25 0.25
MPP  1.0 1.0 0.33 0.33 0.25 0.25
Without index qualification 39 39 10.2 10.2 7.6 10.0
CJ
With index qualification 48 48 12.6 12.6 9.5 11.9
Without index qualification 71 71 17.8 17.7 13.3 13.3
SCJ
With index qualification 81 81 20.2 20.5 15.1 15.1
JMP 39 39 10.2 10.3 7.6 7.6
Without index qualification 74 74 17.8 17.9 13.3 13.3
CALL
With index qualification 78 78 20.2 20.3 15.1 15.1
Without index qualification 70 70 17.8 17.9 13.2 13.2
CALLP
With index qualification 78 78 20.2 20.3 15.1 15.1
RET 50 50 10.4 10.3 9.3 9.6
EI 38 38 9.6 9.2 7.1 7.1
DI 66 66 6.8 7.0 6.5 6.5
IRET 120 120 58.4 57.6 43.2 45.1
Without index qualification 79 79 39.8 17.6 19.0 13.0
SUB
With index qualification 85 85 41.4 19.2 20.0 15.0
Without index qualification 79 79 39.8 17.6 19.0 13.0
SUBP
With index qualification 85 85 41.4 19.2 20.0 15.0
M9084 OFF 2420 2420    
CHG
M9084 ON 2340 2340    
FOR 53 53 11.4 11.6 10.1 10.1
NEXT 41 41 8.0 8.1 7.5 8.2
STOP      
R: Refresh mode, D: Direct mode
