APPENDICES
APP − 47
MELSEC-A
Table 2.1 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
A2AS
(S1)
A2USH-S1
A2USH
board
A2C A52G A0J2H A1FX
Instruction Condition (Device)
R R R R R D R
Unexecuted 2.2 0.99 59 59 59 76 11.7
ON 2.2 0.99 62 62 62 79 11.6
Y
Executed
OFF 2.2 0.99 60 60 60 77 11.7
Unexecuted 2.2 0.99 59 59 59 74 11.7
ON 2.2 0.99 62 62 62 78 11.6
PLS
PLF
M, L, B, F
Executed
OFF 2.2 0.99 61 61 61 76 11.7
Unexecuted 1.4 0.63 3.0 3.0 3.0 3.0 1.0
Y
Executed 4.4 1.99 47 38 47 49 8.1
Unexecuted 1.4 0.63 3.0 3.0 3.0 3.0 1.0
SET
SFTP
M, L, B, F
Executed 4.4 1.99 47 38 47 47 8.1
MPS  0.20 0.09 1.3 1.0 1.3 1.3 0.25
MRD  0.20 0.09 1.3 1.0 1.3 1.3 0.25
MPP  0.20 0.09 1.3 1.0 1.3 1.3 0.25
Without index qualification 6.6 3.08 49 39 49 49 10.0
CJ
With index qualification 6.6 3.08 60 48 60 60 11.9
Without index qualification 6.6 3.08 89 71 89 89 13.3
SCJ
With index qualification 6.6 3.08 101 81 101 101 15.1
JMP 6.6 3.08 49 39 49 49 7.6
Without index qualification 10 4.82 93 74 93 93 13.3
CALL
With index qualification 10 4.82 98 78 98 98 15.1
Without index qualification 10 4.82 87 70 87 87 13.2
CALLP
With index qualification 10 4.82 98 78 98 98 15.1
RET 7.0 3.19 63 50 63 63 9.3
EI 3.0 1.08 47 38 47 47 7.1
DI 3.2 1.08 82 66 82 82 6.5
IRET 3.4 1.08 150 120 150 150 43.2
Without index qualification   98 79 98 98 19.0
SUB
With index qualification   107 85 107 107 20.0
Without index qualification   98 79 98 98 19.0
SUBP
With index qualification   107 85 107 107 20.0
M9084 OFF 450  3025 2420 3025 3025 
CHG
M9084 ON 301  2925 2340 2925 2925 
FOR 5.8 2.73 67 53 67 67 10.1
NEXT 8.0 3.47 51 41 51 51 7.5
STOP       
R: Refresh mode, D: Direct mode
