APPENDICES
APP − 52
MELSEC-A
Table 2.2 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
A2AS (S1)
A2USH-S1
A2USH
board
A2C A52G A0J2H A1FX
Direct Mode
Instruction Condition
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Other
than X, Y
X, Y
Refresh
Mode
+ S D 2.8 1.28 55 44 55 56 74 8.7
+P S D 2.8 1.28 55 44 55 56 74 8.6
D+ S D 4.0 1.82 86 69 86 87 113 13.7
D+P S D 4.0 1.82 86 69 86 87 113 13.6
+ S1 S2 D 3.2 1.45 96 77 96 97 129 15.3
+P S1 S2 D 3.2 1.45 96 77 96 97 129 15.2
D+ S1 S2 D 4.6 2.09 124 99 124 124 308 19.3
D+P S1 S2 D 4.6 2.09 124 99 124 124 308 19.4
- S D 2.8 1.27 56 45 56 57 74 8.7
-P S D 2.8 1.27 56 45 56 57 74 8.6
D- S D 4.0 1.82 86 69 86 87 113 13.7
D-P S D 4.0 1.82 86 69 86 87 113 13.6
- S1 S2 D 3.2 1.45 99 79 99 99 134 15.7
-P S1 S2 D 3.2 1.45 99 79 99 99 134 15.8
D- S1 S2 D 4.6 2.09 124 99 124 124 163 20.3
D-P S1 S2 D 4.6 2.09 124 99 124 124 163 20.4
∗ S1 S2 D 3.4 1.55 118 94 118 119 211 16.5
∗P S1 S2 D 3.4 1.55 118 94 118 119 211 16.6
D∗ S1 S2 D 20 7.45 426 341 426 426 463 73.7
D∗P S1 S2 D 20 7.45 426 341 426 426 463 73.6
/ S1 S2 D 11 5.18 128 102 128 129 124 17.7
/P S1 S2 D 11 5.18 128 102 128 129 124 17.4
D/ S1 S2 D 36 15.72 491 393 491 493 516 80.1
D/P S1 S2 D 36 15.72 491 393 491 493 516 80.2
INC 2.0 0.91 36 29 36 37 47 5.7
INCP 2.0 0.91 36 29 36 37 47 5.4
DINC 2.4 1.09 53 42 53 53 166 8.1
DINCP 2.4 1.09 53 42 53 53 166 7.9
DEC 2.0 0.91 39 31 39 39 49 6.1
DECP 2.0 0.91 39 31 39 39 49 5.9
DDEC 2.4 1.09 53 42 53 53 67 8.1
DDECP 2.4 1.09 53 42 53 53 67 8.1
