APPENDICES
APP − 53
MELSEC-A
Table 2.2 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
AnS A1SJH/A1SH A2SH (S1)
Direct Mode
Instruction Condition
Refresh
Mode
Other than
X, Y
X, Y
Refresh
Mode
Direct
Mode
Refresh
Mode
Direct
Mode
B+ S D 123 123 183 33.6 34.1 25.3 25.2
B+P S D 123 123 183 34.0 34.3 25.2 25.0
DB+ S D 175 176 280 47.0 47.5 35.2 35.2
DB+P S D 175 176 280 46.8 47.7 35.4 35.0
B+ S1 S2 D 129 129 192 35.2 35.7 26.5 26.4
B+P S1 S2 D 129 129 192 35.2 35.5 26.6 26.2
DB+ S1 S2 D 187 186 294 50.2 50.9 37.7 37.8
DB+P S1 S2 D 187 186 294 50.2 50.5 37.5 37.8
B- S D 125 125 185 33.2 33.7 24.9 24.8
B-P S D 125 125 185 33.0 33.7 24.9 24.6
DB- S D 175 175 280 46.8 47.3 35.3 35.0
DB-P S D 175 175 280 46.8 47.3 35.1 35.0
B- S1 S2 D 133 133 203 36.2 36.9 27.3 27.0
B-P S1 S2 D 133 133 203 36.2 36.7 27.1 27.0
DB- S1 S2 D 185 186 294 50.4 50.6 38.1 37.8
DB-P S1 S2 D 185 186 294 50.4 51.1 37.9 37.4
B∗ S1 S2 D 299 300 358 79.8 80.1 60.1 59.4
B∗P S1 S2 D 299 300 358 80.0 80.1 59.7 59.8
DB∗ S1 S2 D 941 939 1044 245.6 246.3 184.3 184.2
DB∗P S1 S2 D 941 939 1044 245.8 246.1 184.3 184.2
B/ S1 S2 D 235 236 274 61.4 61.7 46.2 46.6
B/P S1 S2 D 235 236 274 61.2 61.7 46.1 46.6
DB/ S1 S2 D 896 894 954 246.4 246.9 185.1 184.8
DB/P S1 S2 D 896 894 954 246.0 276.5 184.5 184.8
BCD 82 83 90 22.0 22.3 16.3 16.5
BCDP 82 83 90 22.0 22.5 16.7 16.6
DBCD 219 220 284 59.2 59.7 44.3 44.4
DBCDP 219 220 284 59.2 59.7 44.5 44.8
BIN 79 78 86 20.8 21.5 15.7 16.0
BINP 79 78 86 20.8 21.3 15.7 15.8
DBIN 215 216 280 58.2 58.9 43.9 43.8
DBINP 215 216 280 58.2 58.9 43.7 43.8
