APPENDICES
APP − 54
MELSEC-A
Table 2.2 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
A2AS (S1)
A2USH-S1
A2USH
board
A2C A52G A0J2H A1FX
Direct Mode
Instruction Condition
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Other
than X, Y
X, Y
Refresh
Mode
B+ S D 6.4 2.82 154 123 154 154 229 25.3
B+P S D 6.4 2.82 154 123 154 154 229 25.2
DB+ S D 34 15.17 219 175 219 221 351 35.2
DB+P S D 34 15.17 219 175 219 221 351 35.4
B+ S1 S2 D 14 6.54 161 129 161 162 241 26.5
B+P S1 S2 D 14 6.54 161 129 161 162 241 26.6
DB+ S1 S2 D 31 13.90 234 187 234 233 368 37.7
DB+P S1 S2 D 31 13.90 234 187 234 233 368 37.5
B- S D 6.2 2.73 154 125 154 156 232 24.9
B-P S D 6.2 2.73 154 125 154 156 232 24.9
DB- S D 32 14.09 219 175 219 219 351 35.3
DB-P S D 32 14.09 219 175 219 219 351 35.1
B- S1 S2 D 14 6.18 166 133 166 167 254 27.3
B-P S1 S2 D 14 6.18 166 133 166 167 254 27.1
DB- S1 S2 D 29 12.82 231 185 231 233 368 38.1
DB-P S1 S2 D 29 12.82 231 185 231 233 368 37.9
B∗ S1 S2 D 14 6.45 374 299 374 376 448 60.1
B∗P S1 S2 D 14 6.45 374 299 374 376 448 59.7
DB∗ S1 S2 D 89 37.16 1176 941 1176 1174 1306 184.3
DB∗P S1 S2 D 89 37.16 1176 941 1176 1174 1306 184.3
B/ S1 S2 D 11 4.81 294 235 294 296 343 46.2
B/P S1 S2 D 11 4.81 294 235 294 296 343 46.1
DB/ S1 S2 D 62 25.07 1120 896 1120 1118 1193 185.1
DB/P S1 S2 D 62 25.07 1120 896 1120 1118 1193 184.5
BCD 3.0 1.37 103 82 103 104 113 16.3
BCDP 3.0 1.37 103 82 103 104 113 16.7
DBCD 13 5.72 274 219 274 276 356 44.3
DBCDP 13 5.72 274 219 274 276 356 44.5
BIN 3.0 1.36 99 79 99 98 108 15.7
BINP 3.0 1.36 99 79 99 98 108 15.7
DBIN 6.0 2.73 269 215 269 271 351 43.9
DBINP 6.0 2.73 269 215 269 271 351 43.7
