Table 2.3 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
A2AS (S1)
A2USH-S1
A2USH
board
A2C A52G A0J2H A1FX
Direct Mode
Instruction Condition
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Other
than X, Y
X, Y
Refresh
Mode
WAND S D 2.8 1.29 74 60 74 73 90 11.5
WANDP S D 2.8 1.29 74 60 74 73 90 11.5
DAND 13 5.75 174 140 174 173 300 27.1
DANDP 13 5.75 174 140 174 173 300 27.1
WAND S1 S2 D 7.6 3.47 119 96 119 120 190 19.3
WANDP S1 S2 D 7.6 3.47 119 96 119 120 190 19.3
WOR S D 2.8 1.29 76 61 76 75 90 11.1
WORP S D 2.8 1.29 76 61 76 75 90 11.1
DOR 13 5.74 174 140 174 173 300 27.3
DORP 13 5.74 174 140 174 173 300 27.3
WOR S1 S2 D 7.6 3.47 121 97 121 120 190 19.3
SORP S1 S2 D 7.6 3.47 121 97 121 120 190 19.3
WXOR S D 2.8 1.29 74 60 74 73 90 11.5
WXORP S D 2.8 1.29 74 60 74 73 90 11.5
DXOR 13 5.74 174 140 174 173 300 27.1
DXORP 13 5.74 174 140 174 173 300 27.3
WXOR S1 S2 D 7.6 3.47 121 97 121 120 190 19.3
WXORP S1 S2 D 7.6 3.47 121 97 121 120 190 19.3
WXNR S D 3.0 1.38 79 64 79 78 92 11.7
WXNRP S D 3.0 1.38 79 64 79 78 92 11.7
DXNR 15 6.74 177 142 177 175 301 27.5
DXNRP 15 6.74 177 142 177 175 301 27.5
WXNR S1 S2 D 7.8 3.56 122 98 122 120 190 19.3
WXNRP S1 S2 D 7.8 3.56 122 98 122 120 190 19.5
NEG 8.6 3.93 62 50 62 61 107 9.5
NEGP 8.6 3.93 62 50 62 61 107 9.5
ROR n n=3 5.8 2.65 64 52 64 64 64 9.5
RORP n n=3 5.8 2.65 64 52 64 64 64 9.5
RCR n n=3 6.4 2.74 73 59 73 73 73 10.9
RCRP n n=3 6.4 2.74 73 59 73 73 73 10.9
