Table 2.3 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
AnS A1SJH/A1SH A2SH (S1)
Direct Mode
Instruction Condition
Refresh
Mode
Other than
X, Y
X, Y
Refresh
Mode
Direct
Mode
Refresh
Mode
Direct
Mode
ROL n n=3 54 53 53 13.2 13.7 9.9 10.0
ROLP n n=3 54 53 53 13.4 13.7 9.9 10.1
RCL n n=3 57 57 57 15.2 15.7 11.3 11.4
RCLP n n=3 57 57 57 15.2 15.5 11.5 11.4
DROR n n=3 70 69 69 18.4 18.7 13.7 13.8
DRORP n n=3 70 69 69 18.2 18.9 13.1 13.7
DRCR n n=3 72 72 72 18.0 18.3 13.5 13.5
DRCRP n n=3 72 72 72 18.0 18.5 13.5 13.4
DROL n n=3 69 69 69 18.4 18.7 13.7 13.8
DROLP n n=3 69 69 69 18.2 18.9 13.1 13.7
DRCL n n=3 68 68 68 18.8 19.1 14.1 14.1
DRCLP n n=3 68 68 68 18.8 18.9 14.1 14.0
SFR D n n=5 74 72 83 18.4 17.5 13.7 13.8
SFRP D n n=5 74 72 83 18.4 18.9 13.7 13.8
n=5 124 123 124 31.6 31.7 23.7 23.8
BSFR D n
n=15 — — — 33.6 33.9 25.1 25.2
n=5 124 123 124 31.6 31.9 23.5 23.5
BSFRP D n
n=15 — — — 33.6 33.9 25.3 25.0
DSFR D n n=5 118 116 — 30.2 30.5 22.5 22.6
DSFRP D n n=5 118 116 — 30.2 30.5 22.7 22.8
SFL D n n=5 74 73 84 19.2 19.5 14.3 14.4
SFLP D n n=5 74 73 84 19.2 19.7 14.3 14.6
n=5 134 133 134 34.4 34.7 25.7 25.8
BSFL D n
n=15 — — — 36.0 36.5 26.9 27.2
n=5 134 133 134 34.4 34.9 25.9 25.8
BSFLP n
n=15 — — — 36.0 36.5 27.1 27.0
DSFL D n n=5 118 17 — 30.4 30.9 22.7 22.8
DSFLP D n n=5 118 17 — 30.4 30.9 22.9 22.8
SER S1 S2 n n=5 200 200 — 49.8 50.1 37.3 37.2
SERP S1 S2 n n=5 200 200 — 49.8 50.3 37.5 37.4
SUM 115 114 131 30.8 31.1 23.1 23.2
SUMP 115 114 131 30.8 31.3 23.3 23.2
DSUM 200 119 231 53.8 54.3 40.3 40.4
DSUMP 200 119 231 53.8 54.3 40.5 40.4
DECO S D n n=2 164 163 216 43.2 43.7 32.3 32.4
DECOP S D n n=2 164 163 216 43.2 43.9 32.5 32.4
SEG 91 91 155 25.7 25.7 19.8 19.7
