APPENDICES
APP − 62
MELSEC-A
Table 2.3 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
A2AS (S1)
A2USH-S1
A2USH
board
A2C A52G A0J2H A1FX
Direct Mode
Instruction Condition
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Refresh
Mode
Other
than X, Y
X, Y
Refresh
Mode
ENCO S D n n=2 38 15.55 204 164 204 203 243 69.5
ENCOP S D n n=2 38 15.55 204 164 204 203 243 69.4
BSET D n n=5 9.6 4.37 112 90 112 112 — 17.7
BSETP D n n=5 9.6 4.37 112 90 112 112 — 17.5
BRST D n n=5 9.6 4.37 121 97 121 120 — 18.7
BRSTP D n n=5 9.6 4.37 121 97 121 120 — 18.7
UNI S D n n=1 31 14.27 163 131 163 163 — 21.5
UNIP S D n n=1 31 14.27 163 131 163 163 — 21.5
DIS S D n n=1 25 11.37 192 154 192 191 — 28.1
DISP S D n n=1 25 11.37 192 154 192 191 — 28.1
ASC 3.4 1.55 150 120 150 150 150 23.1
FIFW 20 9.19 126 101 126 126 154 55.3
FIFWP 20 9.19 126 101 126 126 154 20.5
FIFR 69 32.45 147 118 147 147 167 40.3
FIFRP 69 32.45 147 118 147 147 167 40.3
n2=1 42 33.00 232 190 237 237 237 36.4
LRDP n1 S D n2
n2=32 42 33.00 232 190 237 237 237 36.4
n2=1 49 34.90 246 200 250 250 250 38.8
LWTP n1 D S n2
n2=32 89 54.60 556 446 557 557 557 86.8
n3=1 32 14.50 215 172 215 215 215 32.8
RFRP n1 n2 D n3
n3=16 32 14.50 215 172 215 215 215 32.8
n3=1 34 15.50 218 176 220 220 220 33.4
RTOP n1 n2 S n3
n3=16 34 15.50 218 176 220 220 220 33.6
WDT 5.0 2.28 80 64 80 80 80 12.2
WDTP 5.0 2.28 80 64 80 80 80 12.2
1
condition
contact
33 15.0 964 — 964 964 964 —
50
condition
contacts
1257 571.3 4225 — 4225 4225 4225 —
100
condition
contacts
2503 1137.6 8609 — 8609 8609 8609 —
CHK
Fault check
instruction
150
condition
contacts
3753 1705.7 12671 — 12671 12671 12671 —
