Table 2.3 Instruction Processing Time of Small Size, Compact CPUs (Continue)
Processing Time (µs)
AnS A1SJH/A1SH A2SH (S1)
Direct Mode
Refresh Mode
Direct Mode
Refresh Mode
Direct Mode
Refresh Mode
Instruction Condition
Other than
X, Y
X, Y
Other than
X, Y
X, Y
Other than
X, Y
X, Y
n=1 439 524 150.6 211.6 131.7 188.6
FROM
n=1000
/112
6609 2358 3880.5 1372.6 4576.7 1289.6
n=1 439 524 150.7 211.6 131.8 188.6
FROMP
n=1000
/112
6609 2358 3926.5 1372.6 4624.7 1289.6
n=1 449 529 161.9 211.6 141.8 183.6
DFRO
n=500
/56
6609 2109 3888.5 773.6 4584.7 1257.6
n=1 449 529 161.9 211.6 141.8 183.6
DFROP
n=500
/56
6609 2109 4012.5 773.6 4632.7 1257.6
n=1 449 539 152.4 190.6 135.0 162.6
TO
n=1000
/112
6609 3918 3882.5 1827.6 4568.7 1587.6
n=1 449 539 152.4 190.6 135.0 162.6
TOP
n=1000
/112
6609 3918 3946.5 1827.6 4688.7 1587.6
n=1 454 544 157.2 199.6 138.2 165.6
DTO
n=500
/56
6609 1609 3882.5 1227.6 4584.7 1115.6
n=1 454 544 157.2 199.6 138.2 165.6
DTOP
n=500
/56
6609 1609 3930.5 1227.6 4688.7 1115.6
The processing time shown above is the value when the AD71 is used as special function modules.
*1: n=1000 when other than X and Y is specified with other CPU.
n=112 when X and Y are specified.
*2 n=500 when other than X and Y is specified with other CPU.
n=56 when X and Y are specified.
