Table 2.5 Instruction Processing Time of CPUs (Continue)
Processing Time (µs)
An
AnN, A3V, A73
A3N board
A3H, A3M A2A, A2U
A3A,
A3U, A4U
D D
Instruction Condition
D R
Other
than X, Y
X, Y
R
Other
than X, Y
X, Y
R R
DB+P S1 S2 D 321 187 186 294 274* 274* 308* 31 23
B- S D 210 125 125 185 3.6 3.6 11 6.2 4.7
B-P S D 210 125 125 185 3.6 3.6 11 6.2 4.7
DB- S D 318 175 175 208 47 47 6.2 32 24
DB-P S D 318 175 175 280 47 47 6.2 32 24
B- S1 S2 D 212 133 133 203 23 23 34 14 11
B-P S1 S2 D 212 133 133 203 23 23 34 14 11
DB- S1 S2 D 322 185 186 294 261* 261* 306* 29 22
DB-P S1 S2 D 322 185 186 294 261* 261* 306* 29 22
B∗ S1 S2 D 410 299 300 358 11 11 22 14 11
B∗P S1 S2 D 410 299 300 358 11 11 22 14 11
DB∗ S1 S2 D 1158 941 939 1044 693* 693* 738* 89 67
DB∗P S1 S2 D 1158 941 939 1044 693* 693* 738* 89 67
B/ S1 S2 D 422 235 236 274 25 25 40 11 8.0
B/P S1 S2 D 422 235 236 274 25 25 40 11 8.0
DB/ S1 S2 D 998 896 894 954 748* 748* 793* 62 47
DB/P S1 S2 D 998 896 894 954 748* 748* 793* 62 47
BCD 110 82 83 90 1.6 1.6 9.2 3.0 2.3
BCDP 110 82 83 90 1.6 1.6 9.2 3.0 2.3
DBCD 329 219 220 284 9.4 9.4 25 13 9.5
DBCDP 329 219 220 284 9.4 9.4 25 13 9.5
BIN 104 79 78 86 1.6 1.6 9.2 3.0 2.3
BINP 104 79 78 86 1.6 1.6 9.2 3.0 2.3
DBIN 311 215 216 280 3.6 3.6 19 6.0 4.5
DBINP 311 215 216 280 3.6 3.6 19 6.0 4.5
MOV 72 47 47 57 1.2 1.2 8.8 1.2 0.9
MOVP 72 47 47 57 1.2 1.2 8.8 1.2 0.9
DMOV 104 67 67 87 2.0 2.0 17 3.2 2.4
DMOVP 104 67 67 87 2.0 2.0 17 3.2 2.4
XCH 102 60 61 84 1.8 1.8 9.4 2.8 2.1
XCHP 102 60 61 84 1.8 1.8 9.4 2.8 2.1
DXCH 170 107 107 141 3.6 3.6 19 4.2 3.2
DXCHP 170 107 107 141 3.6 3.6 19 4.2 3.2
CML 68 43 43 57 1.4 1.4 9.0 2.4 1.8
CMLP 68 43 43 57 1.4 1.4 9.0 2.4 1.8
DCML 130 74 74 108 2.6 2.6 18 3.2 2.4
DCMLP 130 74 75 108 2.6 2.6 18 3.2 2.4
BMOV S D n n=96 7498 699 400 7144 132 132 862 72 54
R: Refresh mode, D: Direct mode
* With an A3M, processing time will be 20 µs longer than the indicated time.
