APPENDICES
APP 75
MELSEC-A
Table 2.5 Instruction Processing Time of CPUs (Continue)
Processing Time (µs)
An
AnN, A3V, A73
A3N board
A3H, A3M A2A, A2U
A3A,
A3U, A4U
D D
Instruction Condition
D R
Other
than X, Y
X, Y
R
Other
than X, Y
X, Y
R R
BMOVP S D n n=96 7498 699 400 7144 132 132 862 72 54
FMOV S D n n=96 1118 229 228 1029 66 66 435 32 24
FMOVP S D n n=96 1118 229 228 1029 66 66 435 32 24
R: Refresh mode, D: Direct mode
POINTS
(1) All the basic instructions indicated above are used without index
qualification.
(2) When unexecuted, any instruction is processed during the following time:
An...................................................(Number of steps + 1) x 1.3 (µs)
AnN, A3V, A73 and A3N board......(Number of steps + 1) x 1.0 (µs)
A3H and A3M ................................(Number of steps + 1) x 0.2 (µs)
A2A and A2U.................................(Number of steps + 4) x 0.2 (µs)
A3A, A3U and A4U........................ (Number of steps + 4) x 0.15 (µs)
