APPENDICES
APP − 77
MELSEC-A
Table 2.6 Instruction Processing Time of CPUs (Continue)
Processing Time (µs)
An
AnN, A3V, A73
A3N Board
A3H, A3M A2A, A2U
A3A
A3U, A4U
D D
Instruction Condition
D R
Other
than
X, Y
X, Y
R
Other
than
X, Y
X, Y
R R
ROL n n=5 68 54 53 53 4.6 4.6 4.6 5.8 4.4
ROLP n n=5 68 54 53 53 4.6 4.6 4.6 5.8 4.4
RCL n n=5 74 57 57 57 6.8 6.8 6.8 6.4 4.8
RCLP n n=5 74 57 57 57 6.8 6.8 6.8 6.4 4.8
DROR n n=5 97 70 69 69 11 11 11 11 8.3
DRORP n n=5 97 70 69 69 11 11 11 11 8.3
DRCR n n=5 95 72 72 72 13 13 13 12 9.2
DRCRP n n=5 95 72 72 72 13 13 13 12 9.2
DROL n n=5 101 70 69 69 11 11 11 10 7.8
DROLP n n=5 101 70 69 69 11 11 11 10 7.8
DRCL n n=5 98 68 68 68 13 13 13 12 8.7
DRCLP n n=5 98 68 68 68 13 13 13 12 8.7
SFR D n n=5 102 74 72 83 4.0 4.0 7.8 5.0 3.8
SFRP D n n=5 102 74 72 83 4.0 4.0 7.8 5.0 3.8
BSFR D n n=5 145 124 123 124 116 116 154 29 22
BSFRP D n n=5 145 124 123 124 116 116 154 29 22
DSFR D n n=5 133 118 116  15 15  18.8 14.1
DSFRP D n n=5 133 118 116  15 15  18.8 14.1
SFL D n n=5 106 74 73 84 4.0 4.0 7.8 4.8 3.6
SFLP D n n=5 106 74 73 84 4.0 4.0 7.8 4.8 3.6
BSFL D n n=5 158 134 133 134 116 116 154 28 21
BSFLP n n=5 158 134 133 134 116 116 154 28 21
DSFL D n n=5 134 118 17  16 16  22 17
DSFLP D n n=5 134 118 17  16 16  22 17
SER S1 S2 n n=5 230 200 200  187 187  33 25
SERP S1 S2 n n=5 230 200 200  187 187  33 25
SUM 164 115 114 131 14 14 18 15 11
SUMP 164 115 114 131 14 14 18 15 11
DSUM 267 200 199 231 34 34 38 34 25
DSUMP 267 200 199 231 34 34 38 34 25
R: Refresh mode, D: Direct mode
