APPENDICES
APP − 84
MELSEC-A
(2) Basic instructions
Table 2.8 Instruction Processing Time of QCPU-A (A Mode)
Instruction Processing Time (µs)
Instruction Condition (Device)
QnCPU-A QnHCPU-A
LD= 1.67 0.721
AND= 1.27 0.546
OR= 1.76 0.758
LDD= 4.50 1.94
ANDD= 3.48 1.50
ORD= 4.43 1.91
LD<> 1.92 0.829
AND<> 1.28 0.553
OR<> 1.76 0.758
LDD<> 4.26 1.84
ANDD<> 3.49 1.51
ORD<> 4.18 1.80
LD> 1.92 0.829
AND> 1.28 0.553
OR> 1.76 0.758
LDD> 4.26 1.84
ANDD> 3.49 1.51
ORD> 4.18 1.80
LD>= 1.92 0.829
AND>= 1.28 0.553
OR>= 1.76 0.758
LDD>= 4.26 1.84
ANDD>= 3.49 1.51
ORD>= 4.18 1.80
LD< 1.92 0.829
AND< 1.28 0.553
OR< 1.76 0.758
LDD< 4.26 1.84
ANDD< 3.49 1.51
ORD< 4.18 1.80
LD<= 1.92 0.829
AND<= 1.28 0.553
OR<= 1.76 0.758
LDD<= 4.26 1.84
ANDD<= 3.49 1.51
ORD<= 4.18 1.80
