APPENDICES
APP − 85
MELSEC-A
Table 2.8 Instruction Processing Time of QCPU-A (A Mode) (Continue)
Instruction Processing Time (µs)
Instruction Condition (Device)
QnCPU-A QnHCPU-A
+ S D 1.11 0.480
+P S D 1.11 0.480
D+ S D 1.60 0.688
D+P S D 1.60 0.688
+ S1 S2 D 1.27 0.548
+P S1 S2 D 1.27 0.548
D+ S1 S2 D 1.83 0. 790
D+P S1 S2 D 1.83 0.790
- S D 1.11 0.480
-P S D 1.11 0.480
D- S D 1.60 0.688
D-P S D 1.60 0.688
- S1 S2 D 1.27 0.548
-P S1 S2 D 1.27 0.548
D- S1 S2 D 1.83 0.790
D-P S1 S2 D 1.83 0.790
S1 S2 D 1.36 0.586
P S1 S2 D 1.36 0.586
D S1 S2 D 7.97 3.43
D P S1 S2 D 7.97 3.43
/ S1 S2 D 4.38 1.89
/P S1 S2 D 4.38 1.89
D/ S1 S2 D 14.4 6.20
D/P S1 S2 D 14.377 6.20
INC 0.798 0.344
INCP 0.798 0.344
DINC 0.956 0.412
DINCP 0.956 0.412
DEC 0.798 0.344
DECP 0.798 0.344
DDEC 0.956 0.412
DDECP 0.956 0.412
B+ S D 2.55 1.10
B+P S D 2.55 1.10
DB+ S D 13.6 5.86
DB+P S D 13.6 5.86
B+ S1 S2 D 5.58 2.40
B+P S1 S2 D 5.58 2.40
DB+ S1 S2 D 12.4 5.32
DB+P S1 S2 D 12.4 5.32
