APPENDICES
APP − 86
MELSEC-A
Table 2.8 Instruction Processing Time of QCPU-A (A Mode) (Continue)
Instruction Processing Time (µs)
Instruction Condition (Device)
QnCPU-A QnHCPU-A
B- S D 2.47 1.07
B-P S D 2.47 1.07
DB- S D 12.7 5.48
DB-P S D 12.7 5.48
B- S1 S2 D 5.58 2.40
B-P S1 S2 D 5.58 2.40
DB- S1 S2 D 11.6 4.99
DB-P S1 S2 D 11.6 4.99
B S1 S2 D 5.58 2.40
B P S1 S2 D 5.58 2.40
DB S1 S2 D 35.5 15.3
DB P S1 S2 D 35.5 15.3
B/ S1 S2 D 4.38 1.89
B/P S1 S2 D 4.38 1.89
DB/ S1 S2 D 24.7 10.7
DB/P S1 S2 D 24.7 10.7
BCD 1.19 0.51
BCDP 1.19 0.51
DBCD 5.18 2.23
DBCDP 5.18 2.23
BIN 1.19 0.51
BINP 1.19 0.51
DBIN 2.39 1.03
DBINP 2.39 1.03
MOV 0.482 0.208
MOVP 0.482 0.208
DMOV 1.27 0.548
DMOVP 1.27 0.548
XCH 1.11 0.480
XCHP 1.11 0.480
DXCH 1.61 0.722
DXCHP 1.61 0.722
CML 0.956 0.412
CMLP 0.956 0.412
DCML 1.27 0.548
DCMLP 1.27 0.548
BMOV S D n n=96 28.7 12.4
BMOVP S D n n=96 28.7 12.4
FMOV S D n n=96 12.7 5.48
FMOVP S D n n=96 12.7 5.48
