APPENDICES
APP − 89
MELSEC-A
Table 2.9 Instruction Processing Time of QCPU-A (A Mode) (Continue)
Instruction Processing Time (µs)
Instruction Condition (Device)
QnCPU-A QnHCPU-A
ROR n n=5 2.31 0.997
RORP n n=5 2.31 0.997
RCR n n=5 2.55 1.10
RCRP n n=5 2.55 1.10
ROL n n=5 2.31 0.997
ROLP n n=5 2.31 0.997
RCL n n=5 2.55 1.10
RCLP n n=5 2.55 1.10
DROR n n=5 4.38 1.89
DRORP n n=5 4.38 1.89
DRCR n n=5 4.78 2.06
DRCRP n n=5 4.78 2.06
DROL n n=5 3.99 1.72
DROLP n n=5 3.99 1.72
DRCL n n=5 4.78 2.06
DRCLP n n=5 4.78 2.06
SFR D n n=5 1.99 0.86
SFRP D n n=5 1.99 0.86
BSFR D n n=5 11.6 4.99
BSFRP D n n=5 11.6 4.99
DSFR D n n=5 7.49 3.23
DSFRP D n n=5 7.49 3.23
SFL D n n=5 1.91 0.82
SFLP D n n=5 1.91 0.82
BSFL D n n=5 11.1 4.80
BSFLP D n n=5 11.1 4.80
DSFL D n n=5 8.77 3.78
DSFLP D n n=5 8.77 3.78
SER S1 S2 n n=5 13.2 5.67
SERP S1 S2 n n=5 13.2 5.67
