APPENDICES
APP − 90
MELSEC-A
Table 2.9 Instruction Processing Time of QCPU-A (A Mode) (Continue)
Instruction Processing Time (µs)
Instruction Condition (Device)
QnCPU-A QnHCPU-A
SUM 5.98 2.58
SUMP 5.98 2.58
DSUM 13.6 5.59
DSUMP 13.6 5.59
DECO S D n n=2 11.1 4.80
DECOP S D n n=2 11.1 4.80
SEG 2.55 1.10
ENCO S D n n=2 15.2 6.54
ENCOP S D n n=2 15.2 6.54
BSET D n n=5 3.82 1.65
BSETP D n n=5 3.82 1.65
BRST D n n=5 3.82 1.65
BRSTP D n n=5 3.82 1.65
UNI S D n n=4 12.4 5.32
UNIP S D n n=4 12.4 5.32
DIS S D n n=4 9.96 4.29
DISP S D n n=4 9.96 4.29
ASC 1.36 0.586
FIFW 18.0 3.44
FIFWP 7.98 3.44
FIFR 27.5 11.8
FIFRP 27.5 11.8
n2=1 33.0 27.4
LRDP n1 S D n2
n2=32 33.0 27.4
n2=1 34.9 29.0
LWTP n1 S D n2
n2=32 54.6 45.3
n3=1 14.5 12.0
RFRP n1 n2 D n3
n3=32 14.5 12.0
n3=1 15.5 12.9
RTOP n1 n2 S n3
n3=32 15.5 12.9
